Thundercomm TurboX C610 Open Kit
$ tinymix set "SLIM_0_RX Channels" "Two"
$ tinymix set "RX INT7_1 MIX1 INP0" "RX0"
$ tinymix set "RX INT8_1 MIX1 INP0" "RX1"
$ tinymix set "COMP7 Switch" "1"
$ tinymix set "COMP8 Switch" "1"
$ tinymix set "SpkrLeft COMP Switch" "1"
$ tinymix set "SpkrLeft BOOST Switch" "1"
$ tinymix set "SpkrLeft VISENSE Switch" "1"
$ tinymix set "SpkrLeft SWR DAC_Port Switch" "1"
$ tinymix set "SpkrRight COMP Switch" "1"
$ tinymix set "SpkrRight BOOST Switch" "1"
$ tinymix set "SpkrRight VISENSE Switch" "1"
$ tinymix set "SpkrRight SWR DAC_Port Switch" "1"
$ tinymix set "SLIMBUS_0_RX Audio Mixer MultiMedia1" "1"
$ tinyplay /data/audiotest.wav
(3) Disable audio path
# adb shell
$ tinymix set "SLIM RX0 MUX" "ZERO"
$ tinymix set "CDC_IF RX0 MUX" "SLIM RX0"
$ tinymix set "SLIM RX1 MUX" "ZERO"
$ tinymix set "CDC_IF RX1 MUX" "SLIM RX1"
$ tinymix set "SLIM_0_RX Channels" "One"
$ tinymix set "RX INT7_1 MIX1 INP0" "ZERO"
$ tinymix set "RX INT8_1 MIX1 INP0" "ZERO"
$ tinymix set "COMP7 Switch" "0"
$ tinymix set "COMP8 Switch" "0"
$ tinymix set "SpkrLeft COMP Switch" "0"
$ tinymix set "SpkrLeft BOOST Switch" "0"
$ tinymix set "SpkrLeft VISENSE Switch" "0"
$ tinymix set "SpkrLeft SWR DAC_Port Switch" "0"
$ tinymix set "SpkrRight COMP Switch" "0"
$ tinymix set "SpkrRight BOOST Switch" "0"
$ tinymix set "SpkrRight VISENSE Switch" "0"
$ tinymix set "SpkrRight SWR DAC_Port Switch" "0"
$ tinymix set "SLIMBUS_0_RX Audio Mixer MultiMedia1" "0"
