Input / Output and Def�n�t�on of Other Parameters :
First of all, your device reaches you with the parameters entered. To enter the parameters,
it is sufficient to hold down the Stop button for 2 seconds. You will see the P0 parameter.
P0 parameter has no function. You can change between parameters using the + and - keys.
To exit the parameter menu, if you go back to the P0 parameter and hold down the Stop key,
your pump will come to Stop mode and you can start it again with the + key.
LIST OF PARAMETERS
P1 - Selection of Display
P2 - Empty
P3 - Maximum Watt value of device
P4 - Target frequency at manuel mode
P5 - Pressure meter value of running
P6 - Running Mode
P7 - Running cycle of night mode
P8 - Cross-device Master-Slave selection
P9 - Device BMS communication addresses
P14 - Factory reset
P40 - Last failure unit
F1.....20 Last 20 failure

FAILURE CODES:

E 1 Foc runtime error
E 2 High Voltage error
E 4 Low Voltage error
E 8 High temperature error
E 16 Engine failed to start
E 32 Motor Feedback (rotation speed) error
E 64 Over current (Motor short circuit) error
E 128 Software (Software error)
D1N1, D1N2, dry contact pump running, malfunction etc. It is the link for information such as.
BMS; It is an RS485 connection with building automation.
It is an RS485 connection for communication between devices.
Relay connection is used to make another automation with the relay while the device is running.
TERMINAL CONNECTION SCHEME
0 Watt -
1 Meter (Mt) -
2 Current (A) -
3 Cycle (RPM) -
(1500 - 4600 Rpm)
(2.0 - 12.0 Mt)
0 - Automatic variable pressure
1 - Automatic stable pressure
2 - Manuel running
3 - Night mode
(1700 - 4600 Rpm)
(0 - 4)
(0 - 255)
(0 -1)
* "Attention!
If you get an "error code"
warning on the screen, please
contact our technical service."
