Parts List

Parts List
Item Qty Part No .
1 2 205807
2 2 202675
3 6 203589
4 1 201129
5 1 240017
6 5 205678
7 1 58800001
8 9 206340
9 12 203218
10 10 202651
11 6 203099
12 1 509000
13 1 240027
14 2 265500
15 4 202587
16 3 206269
17 1 908525
18 1 908528
Description
U-Bolt, Round 3/8-16 x 4.68
Clamp, Saddle
Bolt, Hex Head, 5/16-18 x 1-1/4"
Long
Spacer, 1.8 Long
Bolt, Hex Head, 1/4-20 x 2-1/4"
Long
Bolt, Hex Head, 1/2-13 x 7" Long
Label, Warning
Locknut, Hex Head, 1/2-13
Washer, Flat, 5/16
Washer, Flat, 1/2
Locknut, Nylon Insert, 5/16
Label, Height-Adjustment
Nut, Hex, Locking 1/4-20
Bolt, Hex Head, 1/2-13 x 1" Long
Spacer, Plastic, 1" Long
Spacer, Metal, .75 O.D., 4" Long
Bracket, Pole
Bracket, Jack Support, Right
Item Qty Part No .
19 1 908529
20 2 910846
21 1 206234
22 1 806259
23 2 916206
24 1 818093
25 2 204620
26 1 916349
27 1 916350
28 1 211236
29 2 220150
30 4 901883
31 2 201656
32 4 265533
33 4 205593
34 4 203232
35 2 90096401
22
Description
Bracket, Jack Support, Left
Bracket, Elevator
Sleeve, Plastic, Height Indicator
Handle Assembly, Crank
Struts, Board Support
Screw Jack Assembly
Spacer, Plastic, .73 O.D., 1.7"
Long
Bracket, Angle, RIGHT
Bracket, Angle, LEFT
Label, Height-Indicator
U-Bolt, Square, 1/2-13 x 5
Tube, Elevator
Spacer, Metal .3.5" Long
Washer, Flat, Nylon
Locknut, Nylon Insert, 3/8-16
Washer, 3/8
Bracket, Board
