Assemble the Elevator Structure/Mechanism
Required Parts:
#6 Bolt, Hex Head, 1/2-13 x 7"
Long
#14 Spacer, 1 .8 Long
#30 Tube, Elevator
Completed Elevator Assembly:
#7 Label, Warning
#21 Sleeve, Plastic, Height-
Indicator
#31 Spacer, Metal .3 .5" Long
Assemble the Elevator Structure/Mechanism
#8 Locknut, Hex Head, 1/2-13
#24 Screw Jack Assembly
#32 Washer, Flat, Nylon
15
#10 Washer, Flat, 1/2
#28 Label, Height-Indicator
