Assemble The Elevator Mount - SPALDING U-Turn Lift System Owner's Manual

Universal elevator mount

Table of Contents

Assemble the Elevator Mount

Required Parts:

#1 U-Bolt, Round 3/8-16 x 4 .68

#9 Washer, Flat, 5/16

#18 Bracket, Jack Support,

RIGHT

#27 Bracket, Angle, LEFT

IF YOUR SYSTEM IS EQUIPPED WITH AN ACRYLIC BACKBOARD, EXAMINE THE BACKBOARD FOR ANY DAMAGE THAT

MAY HAVE OCCURRED DURING SHIPMENT. CRACKS IN THE BACKBOARD COULD RESULT IN SUDDEN BREAKAGE. IF

BACKBOARD IS DAMAGED IN ANY WAY PRIOR TO OR AFTER ASSEMBLY, CALL TOLL-FREE NUMBER: U.S.: 1-800-558-5234;

CANADA: 1-800-284-8339; WWW.SPALDING.COM.

Sections A-D are options for elevator mounting.

Poles and mounting locations will vary.

Follow instructions that are packaged with elevator mount for specific assembly details.

A - Completed Elevator Mount to a Square Pole:

#2 Clamp, Saddle

#10 Washer, Flat, 1/2

#19 Bracket, Jack Support, LEFT #23 Struts, Board Support

#29 U-Bolt, Square, 1/2-13 x 5

WARNING

NOTE

#3 Bolt, Hex Head, 5/16-18 x

1-1/4"

#11 Locknut, Nylon Insert, 5/16

#33 Locknut, Nylon Insert,

3/8-16

#8 Locknut, Hex Head, 1/2-13

#17 Bracket, Pole

#26 Bracket, Angle, RIGHT

#34 Washer, 3/8
