Parts List - SPALDING In-Ground Basketball System Owner's Manual

Item Qty. Part No.
1 1 968860
2 1 908265
3 1
4 1
5 4 208959
6 4 208956
7 4 208958
8 1
1
9 1 203457
10 3 204993
11 1 516000
12 1 204940
13 1 204669
14 1 701299
15 2 202666
204521
16 1
17 1 978850
18 1 988855
19 4 204984
20 1 208954
21 16 208953
22 9* 208961
23 1* 208963
24 9 200704
25 8 265575
26 1 205008
27 4* 208957
28 3 208962
29 4 204733
30 2 204735
31 1 204739
32 1 204740
33 2* 206311
34 4 208960
35 1 204921
36 1 204922
37 1 204923
38 4 208484
4 208483
39 1 205794
* You may have extra parts with this model.

PARTS LIST

Description
Pole
Tube, Ground Anchor, Black
Rim Assembly
Net
Nut, Hex, 3/8-16
Washer, Locking, 3/8
Bolt, Hex, Tap, 3/8-16 x 3.5" Long
Backboard, Glass
Backboard, Acrylic
Label, Logo, Vinyl, 2.3" x 2.7"
Rebar, .5" diameter, 18" Long
Label, Height Adjustment
Screw Jack
Spacer, 0.50" I.D. x 0.75" x 4" Long
Rod, Threaded Assembly, 5/8-11 x 19.8", Zinc
Name Plate, Hydra-Rib
Name Plate, Spalding
Cover, Rim
Yoke, Upper, Center, Pole
Yoke, Lower, Center, Pole
Bolt, Hex, 5/8-11 x 2.5" Long
Bolt, Hex, 1/2-13 x 5
Washer, Flat, 0.53" I.D., 1.08" O.D.
Nut, Lock, Nylon Insert, 1/2-13
Bolt, Hex Head, 1/2"-13 x 6"
Washer, Flat, 5/8"
Nut, Hex, 5/8-11
Nut, Hex, 5/8-11, Grade 8
Washer, Flat, 3/8"
Bolt, Hex, 1/2-13 x 9.25"
Screw, #8, 0.50" Long
Height Indicator
Label, Height Indicator, Right
Label, Height Indicator, Left
Spacer, 0.52" I.D. x 0.75" I.D. x .5" Long, Plastic
Bolt, Hex, 1/2-13 x 2.5"
Washer, Barrel
Pin, Hitch
Pin, Cotter, #8
Spacer, Steel
Spacer, Steel
Pad, Foam
ID# 516000
4
06/05
11
3" High
4" Wide
