- Page 1 Version: 1.2 INSTALLATION GUIDE WALL MOUNT CLAWFOOT TUB FAUCET MODEL FINISH S2127CI CHROME S2127NI BRUSHED NICKEL S2127OI OIL RUBBER BRONZE S2127GI GOLD S2127DI MATTE BLACK SUMERAIN SANITARY GROUP WWW.SUMERAIN.COM...
-
Page 2: Before Proceeding
THANK YOU Dear Valued Customer, SUMERAIN would like to take this opportunity to thank you for purchasing SUMERAIN products. It is our sincere hope that you are completely satisfied with your new purchase. All SUMERAIN products are carefully engineered, and factory tested to provide long trouble-free use under normal conditions. This product is easy to install using basic tools and our easy to follow illustrated instructions. -
Page 3: Limited Lifetime Consumer Warranty
If a defect is found in normal residential use, SUMERAIN will, at its election, repair, provide a replacement part or product, or make appropriate adjustment. - Page 4 Shower hose included 1500mm [59-1/16Inch] Shower hose Length Recommend Working water pressure 3 bar ~ 10 bar Net Weight 2.6KG [ 5,73 lbs ] 3.1KG [6,83 lbs ] Gross Weight 387mm[15-1/4”]x262mm[10-5/16”]x178mm[7”] Packing box [L x W x H] SUMERAIN SANITARY GROUP WWW.SUMERAIN.COM...
- Page 5 DIMENSION FRONT VIEW OF FAUCET SIDE VIEW OF FAUCET SUMERAIN SANITARY GROUP WWW.SUMERAIN.COM...
-
Page 6: Installation Steps
2127015 Diverter button 1 PCS 2127016 Cold button 1 PCS 2127017 Hand Shower 1 PCS 2127018 Washer for hand shower 1 PCS If any of these items are missing, please contact SUMERAIN consumer service by email to: supports@sumerain.com SUMERAIN SANITARY GROUP WWW.SUMERAIN.COM... -
Page 7: Installation
63mm (2-1/2”) and max 243mm (9-9/16”), the elbow connector’s face should be Min 12mm (15/32”) and Max 15mm (19/32”) reach out the finish wall surface. Replace existing tub filler faucet maybe need flange ”B” to match if the elbow connectors’ reach is less than 5mm(3/16”) SUMERAIN SANITARY GROUP WWW.SUMERAIN.COM... - Page 8 5.3 Apply Teflon tape on the thread of S-unions (nipple) and then place the flange to S-unions. (Remark: Using flange”B” to replace flange “A” if the elbow connectors’ reach is less than 5mm(3/16”).please contact Sumerain support if you need this optional flange”B”) 5.4 Connect the S-unions to hot&cold supply elbow connectors.
- Page 9 5.5 Install the faucet to S-unions. 5.6 Place a washer between the side hole of the shower cradle and the cone nut of the shower hose. Tighten the cone nut. SUMERAIN SANITARY GROUP WWW.SUMERAIN.COM...
- Page 10 5.7 Turn on both hot and cold valves, let water run for at least one minute, this will clear any debris left in the line. 5.8 Place the washer between shower and shower hose connector, screwing the shower to connector in a clockwise direction SUMERAIN SANITARY GROUP WWW.SUMERAIN.COM...
-
Page 11: Function Inspection
6.1 Turn on hot and cold water supply and check all connection for ensuring no leaking anywhere. 7. FUNCTION INSPECTION 7.1 Turn on the hot/cold knobs separately, the water outflow from the spout, and then turn off the knobs, the water stop out flowing. SUMERAIN SANITARY GROUP WWW.SUMERAIN.COM... - Page 12 7.2 Switch the diverter Knob, the water will rush from the hand shower. INSTALL FINISH SUMERAIN SANITARY GROUP WWW.SUMERAIN.COM...
- Page 13 CLEARNING RECOMMENDATION FOR SUMERAIN PRODUCTS Modern lavatory faucets, kitchen faucets, and showers consist of very different materials to comply with the needs of the market with regard to design and functionality. To avoid damage and returns, it is necessary to consider certain criteria when cleaning.
-
Page 14: Troubleshooting
Leaking from handle . clean the calcification in showerhead nipple Less water come out from showerhead HONGKONG SUMERAIN SANITARY INDUSTRY CO..LIMITED Address: ROOM 1018, HOLLYWOOD PLAZA 610 NATHAN ROAD MONGKOK, KL,HONGKONG Factory Address:25 building Tangkou Industrial Park,Shuikou town, Kaiping City,...
