- Page 1 MODEL: S2141XW Version: 1.1 INSTALLATION GUIDE ROMAN WATERFALL BATHTUB FAUCET MODEL FINISH S2141CW CHROME S2141NW BRUSHED NICEKL S2141DW MATTE BLACK S2141BGW BRUSHED GOLD SUMERAIN SANITARY GROUP WWW.SUMERAIN.COM...
-
Page 2: Before Proceeding
THANK YOU Dear Valued Customer, SUMERAIN would like to take this opportunity to thank you for purchasing SUMERAIN products. It is our sincere hope that you are completely satisfied with your new purchase. All SUMERAIN products are carefully engineered, and factory tested to provide long trouble-free use under normal conditions. This product is easy to install using basic tools and our easy to follow illustrated instructions. -
Page 3: Limited Lifetime Consumer Warranty
If a defect is found in normal residential use, SUMERAIN will, at its election, repair, provide a replacement part or product, or make appropriate adjustment. - Page 4 Valve Type Ceramic Disc Valve Valve Body Material Brass Spout Material Brass Spout Net Weight 2.86lbs Gross Weight 8.81lbs Working water press 29PSI ~ 116PSI Spout Flow Rate 13.1GPM@60PSI Packing box size 415mm[16-11/32’’]x 285mm[11-7/32”] x 105mm[4-1/8”] SUMERAIN SANITARY GROUP WWW.SUMERAIN.COM...
- Page 5 DIMENSION M30x1.5 M30x1.5 M32x1.5 Front view of faucet Side view of faucet SUMERAIN SANITARY GROUP WWW.SUMERAIN.COM...
-
Page 6: Installation Steps
INSTALLATION STEPS 1. BEFORE PROCEEDING WARNING: Read all the instructions completely before proceeding. SUMERAIN recommends calling a professional if you are uncertain about installing this product!, this product should be installed in accordance with all local and state plumbing and building codes. - Page 7 4. INSTALLATION HOLES INSPECTION Verify that the hole sizes and positions in the wall are correct, the optimal diameter of mounting hole optional is 1-3/8”,the max deck thickness is 1-1/4” . SUMERAIN SANITARY GROUP WWW.SUMERAIN.COM...
-
Page 8: Installation
5.1 Turn on your shut-off valve for cleaning the hot and cold water supply pipe before connect to the faucet, allow the water flush 3~5 minutes to flush out dirt and debris. Shut off the water supply again after finish. 5.2 Disassemble diverter valve assembly. SUMERAIN SANITARY GROUP WWW.SUMERAIN.COM... - Page 9 5.3 Attach the diverter valve body to spout. 5.4 Attach and Install the diverter knob to diverter rod. SUMERAIN SANITARY GROUP WWW.SUMERAIN.COM...
- Page 10 5.5 Position spout onto the hole of mounting surface, attach rubber washer on spout shank and fasten with shank locknut by wrench and screw driver from underneath. 5.6 Attach the tee to diverter valve body. SUMERAIN SANITARY GROUP WWW.SUMERAIN.COM...
- Page 11 5.7 Fasten the tee with locknut. 5.8 Install the hand shower hose adapter to diverter valve body. SUMERAIN SANITARY GROUP WWW.SUMERAIN.COM...
- Page 12 5.10 Place the valve body onto mounting surface, attach the rubber washer and locknut from underneath of mounting surface, Then reposition escutcheons as necessary to a desired height. Repeat the same procedure for the right cold valve assembly. SUMERAIN SANITARY GROUP WWW.SUMERAIN.COM...
- Page 13 5.11 Place the hand shower holder onto mounting surface, attach the rubber washer and locknut from underneath of mounting surface, fasten with locknut by wrench from underneath. 5.12 Connecting the cold water valve body and hot water valve body to diverter tee with flexible hoses. SUMERAIN SANITARY GROUP WWW.SUMERAIN.COM...
- Page 14 5.13 Connecting the cold water valve body and hot water valve body to tee with shower hoses. 5.14 Connecting the hand shower to shower hose. SUMERAIN SANITARY GROUP WWW.SUMERAIN.COM...
- Page 15 The water inlet connecting of hot and cold Valve body is G1/2” [1/2 BSPP], US, CA customers may require NPT cover to BSPP adapter for connecting. 6. INSPECTION 6.1 Turn on hold and cold water supply and check all connection for ensuring no leaking anywhere. INSTALL FINISH SUMERAIN SANITARY GROUP WWW.SUMERAIN.COM...
- Page 16 Please note: if the surface is already damaged, the effect of cleaning materials will cause further damage. Components with damaged surfaces must be replaced or injury could result. Damage caused by improper treatment is not covered under the warranty. HONGKONG SUMERAIN SANITARY INDUSTRY CO., LIMITED Address: ROOM 1018, HOLLYWOOD PLAZA 610 NATHAN ROAD MONGKOK, KL,HONGKONG...
