- Page 1 MODEL: S2095CW Version: 3.0 ROMAN WATERFALL BATHTUB FAUCET MODEL FINISH S2095CW CHROME S2095NW BRUSHED NICEKL S2095DW MATTE BLACK S2095BGW BRUSHED GOLD...
- Page 2 Dear Valued Customer, SUMERAIN would like to take this opportunity to thank you for purchasing SUMERAIN products. It is our sincere hope that you are completely satisfied with your new purchase. All SUMERAIN products are carefully engineered, and factory tested to provide long trouble-free use under normal conditions. This product is easy to install using basic tools and our easy to follow illustrated instructions.
- Page 3 If a defect is found in normal residential use, SUMERAIN will, at its election, repair, provide a replacement part or product, or make appropriate adjustment.
- Page 4 Function Bathtub Faucets Feature Waterfall Style Contemporary Finish Chrome/Brushed Nickel/Brushed Gold/Matte Black Installation Holes Three Holes Number of Handles One knobs Faucet Total Height 8-25/32” [ 223mm] Spout Reach 3-27/32” [98mm] Spout Width 7-25/32” [198mm] Spout Height 4-11/32” [110mm] Max deck thickness 1.0”...
- Page 5 FRONT VIEW OF FAUCET SIDE VIEW OF SPOUT...
- Page 6 SIDE VIEW OF CONTROL VALVE FRONT VIEW OF CONTROL VALVE...
-
Page 7: Before Proceeding
G1/2 Connector hose 1PCS 2095006 2095016 Screw 2PCS 1.5m Sprayer hose 1PCS 2095007 2095017 Handshower 1PCS 2095008 Hand shower sleeve 1PCS 2095009 Handshower holder 1PCS 2095010 If any of these items are missing, please contact SUMERAIN consumer service by email to: supports@sumerain.com... - Page 8 4. INSTALLATION HOLES INSPECTION Verify that the hole sizes and positions in the wall are correct,the diameter of mounting hole recommend 32mm(1-1/4”) and maximum 48mm(1-7/8”) ,the max thickness of deck should be 25mm(1’’)
-
Page 9: Installation
5. INSTALLATION 5.1 Turn on your shut-off valve for cleaning the hot and cold water supply pipe before connect to the faucet, allow the water flush 3~5 minutes to flush out dirt and debris. Shut off the water supply again after done. 5.2 Position spout with shank onto mounting surface, attach rubber washer on spout shank and fasten with spout shank locknut by wrench from underneath. - Page 10 5.3 Screw in the hoses to the bottom of faucet valve assembly as below drawing Bottom view of control valve Hoses connection...
- Page 11 5.4 Place faucet valve assembly with hoses across the mounting surface, secure it with lock nut by screwdriver. Connect the hoses to the spout shank as below drawing...
- Page 12 Install spray support assembly as below. Tighten the rubber washer and fasten with lock nut from underneath. Through the sprayer hose across the center hole of sprayer holder as below diagram, Insert hand shower sleeve in to the hose.
- Page 13 Connect shower hose to the extender hose of control valve as drawing. Install the hand shower into the end of shower hose with correct position.
- Page 14 5.10 Connect all components with flexible hose. 6. INSPECTION 6.1 Turn on hold and cold water supply and check all connection for ensuring no leaking anywhere. INSTALL FINISH...
- Page 15 Modern lavatory faucets, kitchen faucets, and showers consist of very different materials to comply with the needs of the market with regard to design and functionality. To avoid damage and returns, it is necessary to consider certain criteria when cleaning. Cleaning Materials for faucets and showers Acids are a necessary ingredient of cleaning materials for removing lime, however please pay attention to the following points when cleaning faucets and showers:...
- Page 16 HONGKONG SUMERAIN SANITARY INDUSTRY CO., LIMITED Address: ROOM 1018, HOLLYWOOD PLAZA 610 NATHAN ROAD MONGKOK, KL,HONGKONG Factory Address: Floor 3th,No.2 ZhongXing Road,ShuiNuan City Industrial Zone,Shuikou town, Kaiping City, Guangdong Province, China U.S. Support line: +1-866-203-0866 Factory Tel: +86-750-2731579 Web: http://www.sumerain.com E-mail: supports@sumerain.com...
