SUMERAIN S6129P Series Installation Manual

Kitchen faucet with pull down sprayer

Advertisement

Quick Links

INSTALLATION GUIDE
PULL-DOWN KITCHEN SINK FAUCET
MODEL
S6129P-CH
S6129P-BN
S6129P-MB
S6129P-BG
HOT LINE: +1-866-203-0866
FINISH
Chrome
Brushed Nickel
Matte Black
Brushed Gold
MODEL: S6129P-XX
Version: 1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the S6129P Series and is the answer not in the manual?

Questions and answers

Summary of Contents for SUMERAIN S6129P Series

  • Page 1 MODEL: S6129P-XX Version: 1.0 INSTALLATION GUIDE PULL-DOWN KITCHEN SINK FAUCET MODEL FINISH S6129P-CH Chrome S6129P-BN Brushed Nickel S6129P-MB Matte Black S6129P-BG Brushed Gold HOT LINE: +1-866-203-0866...
  • Page 2: Before Proceeding

    THANK YOU Dear Valued Customer, Thank you for choosing SUMERAIN products. We sincerely appreciate your recent purchase and hope you are fully satisfied with your new product. At SUMERAIN, all our products are meticulously designed, engineered, and rigorously tested to ensure long-lasting, trouble-free performance under normal conditions.
  • Page 3: Limited Lifetime Consumer Warranty

    LENGTH OF WARRANTY As stated in the following, any replacement or repaired parts of the product will be covered for the duration of this warranty, which SUMERAIN provides for a period of 1 year from the original date of purchase.
  • Page 4: Functions & Specifications

    FUNCTIONS & SPECIFICATIONS Faucet Type Kitchen Faucet Feature Pull-Down Kitchen Faucet Theme Modern, Contemporary Finish Chrome/Brushed Nickel/Brushed Gold/Matte Black Installation Holes Handle Style Lever Pullout Direction Down Pullout Spray Sensor Sprayer Mounting Type Single Hole Number Of Handles Valve Type Ceramic Disc Spout Reach 8-11/16″...
  • Page 5 DIMENSION SIDE VIEW REAR VIEW...
  • Page 6: Installation Steps

    PSA00012XX 35#Cartridge ASSEMBLE PCT35006XX Supply Hose ASSEMBLE PFH00006XX Bonnet HPB59-1 PSC37125XX Mixer Flexible Hose ASSEMBLE PFH00005XX Bonnet Cap HPB59-1 PFC37125XX Heavy Ball ASSEMBLE PSA61190XX If any of these items are missing, please contact SUMERAIN consumer service by email to: supports@sumerain.com...
  • Page 7: Installation

    4. INSTALLATION HOLES INSPECTION Before installation, confirm that the sink's faucet mounting hole and deck thickness comply with the specifications in the diagram below. A 1-1/4 inch mounting hole diameter and a maximum deck thickness of 1-3/8 inches are recommended. Max:1-3/8″...
  • Page 8 5.3 Connect the two water supply lines to the faucet inlet ports securely, ensuring proper alignment and tight connections. 5.4 Insert the faucet into the mounting hole and slide the lock nut onto the threaded shank from beneath the sink. 5.5 Insert the sprayer hose connector into the outlet connector at the base of the faucet.
  • Page 9: Installation Completed

    5.6 Attach the faucet's hot and cold water inlet hoses to the corresponding hot and cold water supply valves. Use a wrench to securely tighten the mounting nuts, ensuring they are properly fastened. 6. Guide for Spray Head Usage The spray head features two water output modes: stream and shower spray. A button on the spray head enables easy switching between the modes.
