- Page 1 Version: 2.0 WALL MOUNTED BATHROOM SINK FAUCET MODEL FINISH S1393CI CHROME S1393NI BRUSHED NICKEL S1393DI MATTE DARK S1393OI OIL RUBBER BRONZE S1393BGI Brushed Gold...
- Page 2 Dear Valued Customer, SUMERAIN would like to take this opportunity to thank you for purchasing SUMERAIN products. It is our sincere hope that you are completely satisfied with your new purchase. All SUMERAIN products are carefully engineered, and factory tested to provide long trouble-free use under normal conditions. This product is easy to install using basic tools and our easy to follow illustrated instructions.
- Page 3 This warranty covers only your SUMERAIN manufactured product. SUMERAIN warrants this product against defects in material or workmanship as follows: SUMERAIN will repair at no charge for parts only or, at its option, replace any product or part of the product that proves defective because of improper workmanship and/or material, under normal installation, use, service and maintenance.
- Page 4 Function Bathroom Sink Faucets Wall mount Feature Theme Modern ,Contemporary Vessel Configuration Finish Chrome/Nickel brushed/Matte Black/Oil rubber bronze/Gold/Brushed Gold Three Installation Holes Number of Handles Knob Handle style Faucet Total Height Adjustable Spout Reach 192mm [7-1/2 Inch] Spout Height Adjustable Spout rotatable Yes,360degree Installation type...
- Page 5 FRONT VIEW OF FAUCET LEFT VIEW OF FAUCET...
-
Page 6: Before Proceeding
1393106 Escutcheon 2PCS Knob 2PCS 1393107 1393108 Set Screw 2PCS Allen Key 1PCS 13930109 1393110 Aerator 1PCS Flange 1PCS 1393111 1393112 O-Ring 1PCS 1393113 If any of these items are missing, please contact SUMERAIN consumer service by email to: supports@sumerain.com... - Page 7 4. VALVE TRIM INSTALLATION 4.1 Make a mounting rack (normally use woods as materials) for preparing install the rough-in valve trim. The mounting board’s face should be 58mm (2-9/32”) at least and max 88mm(3-15/32”) behind the finish wall surface.
- Page 8 Secure the rough-in valve to the mounting board with screws by Philips screwdriver. 4.3 Turn on your shut-off valve for cleaning the hot and cold water supply tube before connect to the valve trim, allow the water flush 3~5 minutes to flush out dirt and debris. Shut off the water supply again after finish.
- Page 9 4.4 Apply Teflon tape on the thread of tube inlet and then connect to rough-in valve. Rough-in Valve thread for Hot&Cold water inlet: 1/2”-14 NPT ( US, CA ) 4.5 Install finish wall...
- Page 10 4.6 Apply Teflon tape on the thread of spout feed pipe 4.7 Install spout to rough-in valve.
- Page 11 4.8 Attach flange(Escutcheon) to finish wall across spout 4.9 Screw the escutcheons to hot and cold cartridge.
- Page 12 4.10 Slip the escutcheons on to sleeves and attach to finish wall. 4.11 Seal the wall around the escutcheons with waterproof sealant WARNING: Failure to seal the wall can lead to possible water damage.
- Page 13 4.12 Attach and Secure the knobs to cartridge stem with screw by Allen key. 4.13 Install Finish.
- Page 14 ASSEMBLE FINISHED 5. INSPECTION 5.1 Turn on hold and cold water supply and check all connection for ensuring no leaking anywhere. INSTALL FINISH Modern lavatory faucets, kitchen faucets, and showers consist of very different materials to comply with the needs of the market with regard to design and functionality.
- Page 15 HONGKONG SUMERAIN SANITARY INDUSTRY CO..LIMITED Address: ROOM 1018, HOLLYWOOD PLAZA 610 NATHAN ROAD MONGKOK, KL,HONGKONG Factory Address:25 building Tangkou Industrial Park,Shuikou town, Kaiping City, Guangdong Province, China Factory Tel: +86-750-2731579 Web: http://www.sumerain.com E-mail: supports@sumerain.com SUMERAIN AMERICA SUPPORT Address: Pershing Rd Chicago IL 60632...
