- Page 1 MODEL: S1410XW Version: 1.1 WATERFALL VESSEL BATHROOM SINK FAUCET MODEL FINISH S1410CW Chrome S1410NW Brushed Nickel S1410DW Matte Black S1410BGW Brushed Gold...
- Page 2 Dear Valued Customer, SUMERAIN would like to take this opportunity to thank you for purchasing SUMERAIN products. It is our sincere hope that you are completely satisfied with your new purchase. All SUMERAIN products are carefully engineered, and factory tested to provide long trouble-free use under normal conditions. This product is easy to install using basic tools and our easy to follow illustrated instructions.
- Page 3 If a defect is found in normal residential use, SUMERAIN will, at its election, repair, provide a replacement part or product, or make appropriate adjustment.
- Page 4 Function Bathroom Sink Faucets Feature Waterfall Style Contemporary Finish Chrome/Brushed Nickel/Matte Black/Brushed Gold Installation Holes One Holes Number of Handles One Lever Total Height 10-7/32’’ Spout Reach 4-9/16’’ Spout Height 8-1/4’’ Max deck thickness 1-1/4’’ Valve Type Ceramic Disc Cartridge Valve Body Material Brass Spout Material...
- Page 5 SIDE VIEW OF SPOUT...
-
Page 6: Before Proceeding
1PCS 1410005 1410015 O-Ring 1PCS Flexible Supply hose 2PCS 1410006 1410016 Bonnet nut 1PCS 1410007 Cartridge 1PCS 1410008 Spout 1PCS 1410009 O-Ring 1PCS 1410010 If any of these items are missing, please contact SUMERAIN consumer service by email to: supports@sumerain.com... -
Page 7: Installation
4. INSTALLATION HOLES INSPECTION Verify that the hole sizes and positions on the mounting surface are correct, the diameter of mounting hole recommend 1-9/16” (32mm). 5. INSTALLATION 5.1 Turn on your shut-off valve for cleaning the hot and cold water supply pipe before connect to the faucet, allow the water flush 3~5 minutes to flush out dirt and debris. - Page 8 Install the shank to the faucet. Screw the flexible hose in the faucet bottom’s cold and hot water inlet ,.
- Page 9 5.4 Position the faucet with flexible hoses on the mounting surface and tighten the mounting nut by wrench.
- Page 10 5.5 Connect the hot and cold water hose from the faucet to each of the hot and cold supply valve, tighten the mounting nut by wrench. 6. INSPECTION 6.1 Turn on hold and cold water supply and check all connection for ensuring no leaking anywhere. INSTALL FINISH...
- Page 11 Please note: if the surface is already damaged, the effect of cleaning materials will cause further damage. Components with damaged surfaces must be replaced or injury could result. Damage caused by improper treatment is not covered under the warranty. HONGKONG SUMERAIN SANITARY INDUSTRY CO., LIMITED Address: ROOM 1018, HOLLYWOOD PLAZA 610 NATHAN ROAD MONGKOK, KL,HONGKONG...
