- Page 1 MODEL: S6136P-XX Version: 1.0 INSTALLATION GUIDE PULL-DOWN KITCHEN SINK FAUCET MODEL FINISH S6136P-CH Chrome S6136P-BN Brushed Nickel S6136P-MB Matte Black S6136P-BG Brushed Gold HOT LINE: +1-866-203-0866...
-
Page 2: Before Proceeding
THANK YOU Dear Valued Customer, Thank you for choosing SUMERAIN products. We sincerely appreciate your recent purchase and hope you are fully satisfied with your new product. At SUMERAIN, all our products are meticulously designed, engineered, and rigorously tested to ensure long-lasting, trouble-free performance under normal conditions. -
Page 3: Limited Lifetime Consumer Warranty
LENGTH OF WARRANTY As stated in the following, any replacement or repaired parts of the product will be covered for the duration of this warranty, which SUMERAIN provides for a period of 1 year from the original date of purchase. -
Page 4: Functions & Specifications
FUNCTIONS & SPECIFICATIONS Faucet Type Kitchen Faucet Feature Pull-Down Kitchen Faucet Theme Modern ,Contemporary Finish Chrome/Brushed Nickel/Brushed Gold/Matte Black Installation Holes Handle Style Lever Pullout Direction Down Pullout Spray Sensor Sprayer Mounting Type Single Hole Number Of Handles Valve Type Ceramic Disc Height 15-3/4 Inch... -
Page 5: Front View
DIMENSION 3-5/32″ FRONT VIEW 8-7/8″ SIDE VIEW... -
Page 6: Installation Steps
Heavy Ball ASSEMBLF PSA61190XX Bonnet Cap SUS304 PFC37125XX Rubber Washer PRW14015XX Handle Zn Alloy No.3 PHD61360XX Quick Connector ASSEMBLF PSA00026XX Set Screw SUS304 PSC05050XX If any of these items are missing, please contact SUMERAIN consumer service by email to: supports@sumerain.com... -
Page 7: Installation
4. INSTALLATION HOLES INSPECTION Before installation, ensure that the faucet mounting hole on your sink and the deck thickness are within the specified range shown in the diagram below. The recommended mounting hole diameter is 1-1/4 inches (32 mm), and the maximum deck thickness is 1-3/8 inches (35 mm). - Page 8 5.3 Connect the red hose to the hot water inlet and the blue hose to the cold water inlet. Hand-tighten the connections first, then use a wrench to secure them. Avoid over-tightening to prevent damage. 5.4 Place the spout over the mounting holes on the deck, attach the mounting hardware, and tighten it from underneath. 5.5 Insert the sprayer hose connector into the outlet connector located at the bottom of the faucet.
-
Page 9: Installation Completed
5.6 Connect the hot and cold water inlet hoses of the faucet to their corresponding hot and cold water supply valves. Then, use a wrench to securely tighten the mounting nuts, ensuring not to overtighten. 6. Guide for Spray Head Usage The spray head offers two water output modes: stream and shower spray. - Page 10 Address: 1226 NORTH KING ST NUM 522 WILMINGTON, DE 19801 United States Tel: +1(866)203-0866 Web: http://www.sumerain.com E-mail: supports@sumerain.us HONGKONG SUMERAIN SANITARY INDUSTRY CO., LIMITED Address: FLAT/RM 3B 3/F BANK TOWER NOS.351&353 KING'S ROAD NORTH POINT Tel: +86-750-2731579 E-mail: supports@sumerain.com SUMERAIN EUROPE SUPPORT Address: Flottwellstr.15...
