it out and place 32mm diameter filter into it, taking care that dust, dirt and
fingerprints do not get on the filter and the field lens.
A diffuser is built into the condenser of the microscope.
●
IV. Usage of microscope components

1. Illumination brightness adjustment

Turn the light intensity control wheel fully clockwise to the low brightness
●
position.
Set the power switch on the rear of microscope to position "I" (ON)
●
The brightness indicator of Swift Logo in the front of microscope base will
●
light up.
When the light intensity control wheel is turned anti-clockwise to high
●
brightness position, the light intensity will increase.
Automatic power off function:
●
A safety and environmentally friendly feature in Stellar 1. If the brightness
is unchanged for 30 minutes, the microscope illumination will
automatically switch off. Turn the light intensity control wheel and the
illumination will automatically recover.

2. Interpupillary distance adjustment

● Before adjusting the interpupillary distance, bring a specimen into focus
using the 10x objective.
● Adjust the interpupillary distance so that both the right and left field of
view become one.
