an aperture diaphragm closed down to 2/3 of the maximum value.
Color Coded Condenser Aperture Diaphragm
Turning down the diaphragm will lower the resolution and brightness but
●
The aperture diaphragm is coded in color ranges to quickly locate
increase the contrast and depth of focus.
●
aperture diaphragm of by matching objective color ring.
An image with appropriate contrast in most cases can be obtained with
●
Turn the aperture diaphragm to the corresponding range of the objective
an aperture diaphragm closed down to 2/3 of the maximum value.
●
color ring. For example,red range for 4x.
Adjust the aperture diaphragm slightly to get the sharpest image
●
according to specimens.
Color Coded
Aperture
Diaphragm
Turn the aperture diaphragm to the maximum position.
●
●
position.
Turn the light intensity wheel as necessary to increase brightness.
●

10. Use of Phase Contrast (Phase Contrast models only)

A phase contrast model contains condenser with slot, phase contrast
●
slide with phase annulus, phase contrast objectives with built-in phase
plate, and a phase centring telescope for aligning.
Turn the phase contrast objective into position.
●
4X 10X 40X 100X
Darkfield
13
White
Blue
Yellow
Red
4X 10X 40X
Objective Color Ring
100X
