Part 1 - Remote Setup
• Bitrate Control: Choose a bitrate control mode for
H.264 compression.
- CBR (Fixed Bitrate): Maintains the current bitrate
regardless of motion change in the video.
- VBR (Variable Bitrate): Bitrate varies depending
on motion changes in the video. Less movement
places less load on the network and takes up less
storage space.
• Frame Rate: Choose a frame rate setting for video
streaming. The fame rate of the current stream cannot
be higher than the fame rate of the higher stream if
those stream resolutions are same.
• Default Record Stream: Choose a stream to use
for recording. This setting, however, may not apply
if a recording stream has been designated from the
remote program or the SD memory card recording
feature has been enabled. For more information, refer
to the Settings on page 35.
• Multi-View Streaming: Designate a specific area of
the screen and stream images from that area only.
(not supported for the primary stream) Click Setup to
designate a streaming area.
22
Select On and then specify the streaming area's
resolution.
- Resolution Limit: Indicates the maximum
resolution that can be set for the streaming area.
- Resolution: Designate a streaming area.
Designated area is marked in red on the screen. You
can adjust the resolution of the area or reposition
the area by dragging and dropping using the
mouse.
- Current Resolution: Displays the resolution of the
designated streaming area.
• Video Output: Display whether the BNC video
output works or not. The BNC video out may not work
depending on the settings under Video > Streaming.
If multiple users are connected to the camera, the
increase in bandwidth use can lower the frame rate.
