Step 3: Assembly of the Chip Up Bar
1. Attach both butterfly clips (28) to the ends of the barbell plate holders (22).
2. Assemble the chip up bar (26) to both guide rods (16) by using two screws (19).
3. Assemble one connect plate (29) to one stand tube (12) by using two bolts (13), four washers
(4) and two lock nuts (5).
4. Repeat the previous step on the other stand
tube (12).
5. Fasten both connect plates (29) by using
one bolt (27) ad one washer (4) on each side.
No. Name
4 washer
5 lock nut
13 out hexagon bolt
19 hexagon socket screw
26 chip up bar
27 out hexagon bolt
28 butterfly clip
29 L shape connect plate
20
Specification Qty.
Φ10 10
M10 4
M10*75 4
M8 2
1
M10*65 2
2
t4.0*100*102.7 2
