Taurus 3D Smith Machine Assembly And Operating Instructions Manual page 18

Step 2: Assembly of Stand Tubes, Guide Rods, Barbell Rod and Barbell Plate Holders
1. Attach 14 limit nuts (31) and 14 limit columns (30) to each of both stand tubes (12).
2. Assemble one stand tube (12) to the right fix plate (7) by using two bolts (13), four washers (4)
and two lock nuts (5).
3. Fasten the stand tube (12) by using one bolt (15), two washers (4) and one lock nut (5).
4. Assemble tho other stand tube (12) to the left fix plate (10) by using two bolts (13), four washers
(4) and two lock nuts (5).
5. Fasten the stand tube (12) by using one bolt (15), two washers (4) and one lock nut (5).
6. Attach the left safety hook (18) to the second limit column (31) of the stand tube (12) from
below.
7. Attach the right safety hook (17) to the second limit column (31) of the other stand tube (12)
from below.
8. Slide both sliding sleeves (21) at each end of the barbell rod (20).
9. Assemble both barbell plate holders (22) to the ends of the barbell rod (20) by using one screw
(25), one spring gasket (24) and one washer (23) on each side.
10. Attach the hooks of the barbell rod (20) to the 4th limit column (31) of the stand tubes (12) from
above.
11. Slide one guide
through sliding sleeve (21)
and the left safety hook (18) by
using two rubber pads (14).
12. Slide the other guide rod (16)
through sliding sleeve (21) and
the right safety hook (17) by
using two rubber pads (14).
13. Tighten both guide rods (16) by
using one screw (19) on each side.
18
rod (16)
No. Name
4
5
12
13
14
15
16
17
18
19
20
21
22
23
24
25
30
31
washer
lock nut
stand tube
out hexagon bolt
rubber pad
out hexagon bolt
guide rod
safety hook right
safety hook left
hexagon socket screw
without head
barbell rod
sliding sleeve
barbell plate holder
washer
spring gasket
hexagon socket screw
Limit column
Limit nut
3D Smith Machine
Specification Qty.
Φ10 12
M10 6
2
M10*75 4
4
M10*70 2
2
1
1
M8 2
1
2
2
Φ12 2
Φ12 2
M12*40 2
28
28
