Caple DD910WH Technical Information page 7

THE SUCTIONING SYSTEM WORKS PROPERLY BUT
THE EXTRACTABLE UNIT DOES NOT OPEN
THE PUSH -BUTTON PANEL DOES NOT LIGHT UP
- CHECK IF THE ELECTRICAL SYSTEM CONNECTORS
ARE CONNECTED PROPERLY (chapt.2)
- CHECK IF IN THE 9-POLE CONNECTOR, THE INNER
CONTACTS ARE WELL CONNECTED (chapt.2)
- REPLACE THE LINEAR ACTUATOR (chapt.10)
- CHECK THE INNNER CONNECTION OF THE ACTUA-
TOR (chapt.9)
- CHECK IF THE FLAT CONNECTOR IN THE LOWER
PANEL IS PROPERLY CONNECTED
- CHECK IF THE CONNECTOR INSIDE THE EXTRAC-
TABLE UNIT COLUMN IS CONNECTED
(chapt.17)
- CHECK IF THE FLAT IS DAMAGED
- REPLACE THE PUSH-BUTTON PANEL (chapt.17)
