Hoist - Manitowoc Grove RT770E Operator's Manual

LUBRICATION
Lube Point
Item
Description

Hoist

92 Main Hoist
93a Auxiliary Hoist
NOTE: Line up the Fill/Drain Plug with the upper access hole (A). Let hoist sit idle for 20 minutes for an accurate reading.
If oil level is not visible in sight glass, the hoist is underfilled. Oil escaping from vent plug (B) or is more than 3 mm
(0.13 in) from the top of the sight glass is an indication the hoist is overfilled. If hoist is over filled drain the oil from
the Fill/Drain Plug at the upper access hole. When replacing the oil, align the Fill/Drain Plug with the lower access
hole (C) and drain the oil.
Failure to align the Fill/Drain Plug with the upper access hole prior to checking the oil level will result in an
inaccurate reading.
Cable Follower
93b
(Arms)
NOTE: Lubricate more frequently than interval indicated if environmental and/or operating conditions necessitate.
5-32
Approved
Figure No.
Lubricant
AGMA
Extreme
Figure 5-12 Pressure Gear
Lubricant
6829100213
AGMA
Extreme
Figure 5-12 Pressure Gear
Lubricant
6829100213
EP-MPG
Extreme
Pressure
Figure 5-12
Multipurpose
Grease
6829003477
Published 04-04-2017, Control # 446-09
RT770E OPERATOR MANUAL
Lube
Lube Interval
Capacity
• Check and fill every
50 hours or weekly
14.7 l
• Drain and fill every
(15.5 qt)
1000 hours or 12
months
• Check and fill every
50 hours or weekly
14.7 l
• Drain and fill every
(15.5 qt)
1000 hours or 12
months
Thoroughly
250 hours or 3 months
coat
Application
Oil must be visible in
the sight glass and
the level no more
than 3 mm (0.13 in)
from the top of the
sight glass
Oil must be visible in
the sight glass and
the level no more
than 3 mm (0.13 in)
from the top of the
sight glass
Spray on
