Manitowoc Grove RT770E Operator's Manual page 132

SET-UP AND INSTALLATION
6
4
Item
1 Removal Cylinders
2 Cylinder Attach Pins
3 Counterweight Attach Pins
4 6042 kg (13,300 lb) Counterweight
5 Leveling Bolts (4 places)
6 Counterweight Lifting Lugs (4 places)
9. Adjust the four
(Figure 4-22) to eliminate any relative movement
between the counterweight and the turntable.
4-24
1
5 (4 places)
Description
counterweight leveling
Published 04-04-2017, Control # 446-09
6670-1
3
bolts
The crane is now ready for operation with the counterweight
installed.
RT770E OPERATOR MANUAL
1
2
FIGURE 4-21
Leveling Bolts
FIGURE 4-22
