DECEMBER 2018
Power .............................................................. electro-hydraulic
Motor rating @ 12 volts DC ....... 65.0 amp. avg/cycle, 1250 psi
@ 24 volts DC ....... 32.5 amp. avg/cycle, 1250 psi
Hydraulic cylinders .............. 2 ea, 1.5", power-up/gravity-down
A
Stationary
frame
MODEL
width
K2003
45
K2005
47
K2010
49
K5505
47
K5510
49
K5511
47
32DSSK06.D
K-SERIES PUBLIC USE SERVICE MANUAL
APPENDIX 1
LIFT SPECIFICATIONS
K-SERIES PUBLIC USE PLATFORM LIFT
DIMENSIONS (inches)
B
C
Installation
Height
depth
(folded)
(folded)
55
17
55
17
55
17
58
17
58
17
58
17
Rated load capacity .................................... 800 lbs
Manual backup (up) ............................ hand pump
Manual backup (down) ...... pressure release valve
Lift weight ......................................... 340 - 370 lbs
D
E
Usable
Usable
platform
platform
width
length
29
51
31
51
33
54
31
51
33
54
33
51
SPARE PARTS
F
G
Floor-to-
Traveling
Clear entry
ground
frame
travel
width
37
38
37
40
37
42
48
40
48
42
48
42
H
width
29.75
31.25
33.75
31.25
33.75
33.75
4 - 29
