TABLE 1-1: K-SERIES MAJOR COMPONENT TERM DEFINITIONS
TERM
Left, right, front, rear
Baseplate
Bridgeplate
(inboard rollstop)
Bridgeplate load
sensor
Control pendant
Cycle counter
Front platform
section
Front rollstop
Handrail
Hydraulic cylinder
Hydraulic power unit
Manual backup pump
handle
Platform folding
linkage
Platform hinges
Platform light
Rear platform section Rear portion of platform that is folded by linkage located within the vertical arms.
Serial number
Stow-lock catch
Threshold beam
Top and bottom arms (left and right) Upper and lower links that connect vertical arms to baseplate.
Vertical arm
Visual and audible
alarms
Armored Cable and
Cover
32DSSK06.D
K-SERIES PUBLIC USE SERVICE MANUAL
DESCRIPTION
Position references when installed lift is viewed from outside of vehicle.
Bolts to vehicle floor; provides secure foundation for lift structure.
Plate that bridges gap between platform and baseplate when platform is at floor level. Also
acts as a rear rollstop when platform is in motion.
Senses if weight is present on the lowered bridgeplate.
Hand-held device used to control platform motions.
Visible at top rear of housing. It records number of times platform has moved from floor level
to ground and back to floor level.
Front portion of platform that unfolds during deploy and folds during stow. See "Platform fold-
ing linkage".
Front barrier prevents wheelchair from inadvertently rolling off of platform during platform
movement.
(left and right) Provides handhold for standing passenger.
(left and right) Telescoping single-acting cylinders convert hydraulic pressure into platform
lifting and folding force.
Contains hydraulic pump driven by electric motor that produces pressure to raise and fold
platform, and a pressure release valve to unfold and lower it.
Used to operate manual back up-pump (located on hydraulic power unit cover).
(left and right) Links that cause front platform section to unfold as it deploys or fold as it
stows.
Three hinges provide a flexible connection between front and rear platform sections.
(left and right) Provide illumination of platform surface when lift is in use.
This is the location of lift serial number decal.
Engages latch located on bottom of bridgeplate when platform is fully stowed.
(upper and lower) Light-beams detect presence of objects in threshold area.
(left and right) Connects platform to top and bottom arms.
Announce when something has passed over threshold. Activated by threshold beams.
Front Barrier sensor with cable.
END OF TABLE
