Wabtec RICON KlearVue K Series Service Manual page 52

DECEMBER 2018
FIG.
ITEM DESCRIPTION
1 CAM, LIFT CONTROL
2 SWITCH, LIMIT, FOLD CUTOFF
3 BLOCK, FOLD CUTOFF SWITCH OFFSET, 1/4" THICK
4 BLOCK, FOLD CUTOFF SWITCH OFFSET, 3/8" THICK
5 SPRING, RETAINING, UPPER/LOWER SWITCH BLOCK
6 * SWITCH BLOCK ASSEMBLY
6A SWITCH BLOCK
7 ACTUATOR, FOLD CUTOFF
8 SWITCH, LIMIT, FLOOR LEVEL POWER CUTOFF, UP & DOWN
9 KIT, LIMIT SWITCH BLOCK REPLACEMENT
10 SCREW, 4-40 X 1.25 PAN HEAD (BAG OF 10)
11 SCREW, 4-40 X .75 PAN HEAD (BAG OF 10)
12 NUT, HEX, 4-40 (BAG OF 10)
13 ** ELECTRICAL HARNESS, MAIN, W/O INTERLOCK
14 MS, 10-24 X ½ PHIL PAN (BAG OF 10)
15 PIN, EXTENSION FOLD CUTOFF (BAG OF 10)
16 MS 10-24 X 1 3/4 PHIL PAN (BAG OF 10)
17 MS 8-32 X 1 1/4 PHIL PAN (BAG OF 10)
18 NUT, HEX, 8-32 NYLON INSERT (BAG OF 10)
19 TAPE, NON-REFLECTIVE
20 OBS;ENCLOSURE,SENSOR,UNPAINTED
21 SENSOR, PHOTOBEAM, RECEIVER
22 SENSOR, PHOTOBEAM, TRANSMITTER
23 SCREW, RD HEAD, 10-24 X 2" (BAG OF 10)
24 SPRING, COMPRESSION, .30 X 2.06L
25 DIS;ROLLPIN,3/32x1(BAG OF 10)
26 ROLLPIN, .94 X .50 (BAG OF 10)
27 PCB ASSEMBLY, PUBLIC
28 SHORTING PLUG
29 * HARNESS, PCB TO CAM SWITCH
* HARNESS, PCB TO POWER INTERRUPT
* HARNESS, INTERLOCK
* HARNESS, PCB TO PLATFORM
30 KIT, CIRCUIT BREAKER, MAIN (90A) – 12 VOLTS
30A * KIT, CIRCUIT BREAKER, 50 AMP – 24 VOLTS
31 BRIDGEPLATE LOAD SENSOR
32 ROLLSTOP, SENSITIZED
NOTE: (REF) in QTY column is for Referenced Parts Only and are not sold as spare parts.
NOTE: * Item or configuration not shown.
NOTE: ** Does not include all harnesses. Reference Item 29.
32DSSK06.D
K-SERIES PUBLIC USE SERVICE MANUAL
FIGURE 4-4: PUBLIC USE ELECTRICAL SYSTEM
(SUPERSEDED BY 34314)
SPARE PARTS
QTY CONFIG. PART NO.
1 V2-AC-107
1 V2-ES-111
1 V2-ES-78
1 V2-ES-79
1 V2-ES-95
2 V2-ES-82
2 34314
1 V2-AC-089
2 V2-ES-110
2 V2-ES-61
1 15908
1 15909
1 15903
1 33032
1 13304
1 15914
1 29318
1 15906
1 15907
1 35706
2 32295
2 32499
2 32498
1 14497
2 V2-ES-93
1 14498
1 14496
1 33461
1 UL-ES-007
1 33030
1 33031
1 33044
1 33807
1 01010K
1 01291
1 31791
1 51850290
4 - 11
