SPARE PARTS
FIGURE 4-7: K-SERIES DOT PUBLIC USE TRAVELING FRAME ASSY
FIG.
ITEM DESCRIPTION
43 WASHER, KEYED
44 KIT, LATCH RELEASE, 30", W/BLOCKS & HARDWARE
KIT, LATCH RELEASE, 30", W/BLOCKS & HARDWARE
44A KIT, LATCH RELEASE, 32", W/BLOCKS & HARDWARE
KIT, LATCH RELEASE, 32", W/BLOCKS & HARDWARE
44B KIT, LATCH RELEASE, 34", W/BLOCKS & HARDWARE
KIT, LATCH RELEASE, 34", W/BLOCKS & HARDWARE
KIT, LATCH RELEASE, 34", W/BLOCKS & HARDWARE
45 BLOCK, CENTER MOUNTING, BASE LATCH
46 BLOCK, MOUNTING, BASE LATCH
47 BRACKET, STOW LOCK SOLENOID
48 SOLENOID ASSY, 12V, STOW LOCK
49 CLIP, SPRING, BASE LATCH
50 SCREW, FLAT HEAD, 10-24 x 1/2", SST (BAG OF 10)
51 NUT, HEX, NYLON INSERT, 10-24 (BAG OF 10)
52 PIN, SPRING MOUNTING
53 SPRING, STOW LOCK RELEASE, .38OD X 3.5"
54 STAND OFF, LATCH COVER
55 SCREW, HEX HEAD, 5/16-18 X 3/4" (BAG OF 10)
56 SCREW, FLAT HEAD, 5/16-18 X 3/4" (BAG OF 10)
57 SCREW, BUTTON HEAD, 1/4-20 X 1/2", SST (BAG OF 10)
58 COVER, BASE LATCH
59 SCREW, HEX HEAD, 5/16-18 X .625 (BAG OF 10)
60 WASHER, FLAT, .69OD x .34ID x .065 (BAG OF 10)
61 SPRAY PAINT, TOUCH-UP, CHARCOAL
62 BUSHING, E-COVER MOUNT
63 SCREW, HEX HEAD, 1/4-20 X 1 (BAG OF 10)
64 GROMMET, .30ID x .88OD x .44 (BAG OF 10)
65 SHAFT, CONTROL CAM
66 RIVET, BLIND, 3/16OD X 5/8L, STEEL (BAG OF 10)
67 SPRING NUT, 10-24, U-TYPE (BAG OF 10)
68 SCREW, PAN HEAD, 10-24 x 1/2" (BAG OF 10)
69 PLUG, 1" LOW PROFILE, BLACK NYLON
70 KIT, PINCH POINT SHIELD, LH INNER & RH OUTER, W/HARDWARE
70A KIT, PINCH POINT SHIELD, LH INNER & RH OUTER, W/HARDWARE
71 KIT, PINCH POINT SHIELD, LH OUTER & RH INNER, W/HARDWARE
71A KIT, PINCH POINT SHIELD, LH OUTER & RH INNER, W/HARDWARE
72 SADDLE ASSEMBLY
NOTE: (REF) in QTY column is for Referenced Parts Only and are not sold as spare parts.
NOTE: * Item or configuration not shown.
4 - 24
K-SERIES PUBLIC USE SERVICE MANUAL
QTY CONFIG. PART NO.
6 20258
1 K2003 28768
1 K5503 28768
1 K2005 28769
1 K5505 28769
1 K2010 28771
1 K5510 28771
1 K5511 28771
1 V2-AC-102
1 V2-AC-001
1 V2-AC-108
1 V2-ES-127
1 V2-AC-009
1 14426
1 13382
1 V2-PI-095
1 V2-SP-093
2 V2-BU-080
1 15901
1 14499
4 15902
1 V2-CV-123
3 14495
3 13350
1 25340
2 V2-BU-081
2 14493
2 23391
1 V2-PI-091
2 34519
8 11799
8 13304
2 25563
2 K20XX 29178
2 K55XX 29179
2 K20XX 29162
2 K55XX 29163
2 VT-AC-046
