Wabtec RICON KlearVue K Series Service Manual page 56

DECEMBER 2018
FIGURE 4-6: PUBLIC USE FOLDING PLATFORM ASSEMBLY
FIG.
ITEM DESCRIPTION
1 KIT, PNEUMATIC SPRING ASSY, RETROFIT (LH & RH SIDE KIT)
2 SPRING, PNEUMATIC ASSIST
3 ROD END ASSY, WITH HARDWARE
4 KIT, LINK ASSY, RH, YELLOW, 51" LG PLATFORM
KIT, LINK ASSY, RH, YELLOW, 51" LG PLATFORM
KIT, LINK ASSY, RH, YELLOW, 51" LG PLATFORM
KIT, LINK ASSY, RH, YELLOW, 51" LG PLATFORM
KIT, LINK ASSY, RH, YELLOW, 51" LG PLATFORM
4A KIT, LINK ASSY, RH, YELLOW, 54" LG PLATFORM
KIT, LINK ASSY, RH, YELLOW, 54" LG PLATFORM
5 KIT, LINK ASSY, LH, YELLOW, 51" LG PLATFORM
KIT, LINK ASSY, LH, YELLOW, 51" LG PLATFORM
KIT, LINK ASSY, LH, YELLOW, 51" LG PLATFORM
KIT, LINK ASSY, LH, YELLOW, 51" LG PLATFORM
KIT, LINK ASSY, LH, YELLOW, 51" LG PLATFORM
5A KIT, LINK ASSY, LH, YELLOW, 54" LG PLATFORM
KIT, LINK ASSY, LH, YELLOW, 54" LG PLATFORM
6 MAIN SHAFT, 1" DIA X 36.50" (VT-PI-43)
MAIN SHAFT, 1" DIA X 36.50" (VT-PI-43)
6A MAIN SHAFT, 1" DIA X 39.13" (VT-PI-49)
MAIN SHAFT, 1" DIA X 39.13" (VT-PI-49)
6B MAIN SHAFT, 1" DIA X 40.50"
MAIN SHAFT, 1" DIA X 40.50"
MAIN SHAFT, 1" DIA X 40.50"
7 T-NUT, ¼-20, SST (BAG OF 10)
8 TORSION SPRING, LH
9 KIT, ACTUATOR, ROLLSTOP, LH
KIT, ACTUATOR, ROLLSTOP, LH
9A KIT, ACTUATOR, 32"W PLATFORM, W/PLATE & HDWR
KIT, ACTUATOR, 32"W PLATFORM, W/PLATE & HDWR
9B KIT, ACTUATOR, 34"W PLATFORM, W/PLATE & HDWR
KIT, ACTUATOR, 34"W PLATFORM, W/PLATE & HDWR
KIT, ACTUATOR, 34"W PLATFORM, W/PLATE & HDWR
10 ROLLSTOP ASSY, 6"H X 30"W
10 ** ROLLSTOP ASSY, 6"H X 30"W
10 ROLLSTOP ASSY, 6"H X 30"W
10 ** ROLLSTOP ASSY, 6"H X 30"W
NOTE: (REF) in QTY column is for Referenced Parts Only and are not sold as spare parts.
NOTE: * Item or configuration not shown.
NOTE: ** SERIAL NUMBER BREAK E722039
32DSSK06.D
K-SERIES PUBLIC USE SERVICE MANUAL
(SUPERSEDED 32466)
(SUPERSEDED 32466)
SPARE PARTS
QTY CONFIG. PART NO.
2 19318
2 R5-SP-502
2 29224
1 K2003 19522
1 K2005 19522
1 K5503 19522
1 K5505 19522
1 K5511 19522
1 K2010 42039
1 K5510 42039
1 K2003 19522L
1 K2005 19522L
1 K5503 19522L
1 K5505 19522L
1 K5511 19522L
1 K2010 44264
1 K5510 44264
1 K2003 34890
1 K5503 34890
1 K2005 34893
1 K5505 34893
1 K2010 16607
1 K5510 16607
1 K5511 16607
1 14485
1 V2-SP-021
1 K2003 22903
1 K5503 22903
1 K2005 55672
1 K5505 55672
1 K2010 55671
1 K5510 55671
1 K5511 55671
1 K2003 39951
1 K2003 51850290
1 K5503 39951
1 K5503 51850290
4 - 15
