FIG.
ITEM DESCRIPTION
1 KIT, SOLENOID, 12V, SPST
2 BUS BAR, ISKRA MOTOR
3 KIT, MOTOR ASSY, W/BRACKET, 12V
4 KIT, PRESSURE SWITCH, WITH INSTRUCTIONS
5 * LIGHT ASSY, INDICATOR, 12V
5A PCB, PUMP LED ASSY, 12V (P/N 35739)
6 KIT, SPOOL VALVE, WITH DECELERATION, 12V
6A * KIT, SPOOL VALVE, WITH DECELERATION, 24V
7 KIT, SEAL, PUMP, MANUAL BACK-UP
8 BACK-UP PUMP, MANUAL
9 FITTING ASSY, SNL, 1/4J X 1/4J, STEEL
10 CABLE CLAMP, 3/16", NYLON (BAG OF 10)
11 CIRCUIT BREAKER KIT, 8 AMP, W/HDWR & DECAL
12 BRACKET, SOLENOID
13 PIN & RETAINING RING
14 MOTOR ASSY, 12V, 3", ISKRA
15 DECAL, 8 AMP CIRCUIT BREAKER
16 ADAPTER, .625 D-HOLE TO .484 ROUND
17 SCREW, SHC, 1/4-20 X 2.25L (BAG OF 10)
18 FITTING, SRT, 1/4J, STEEL
19 LIGHT, LIFT ARMED INDICATOR, 12V, GREEN
19A * LIGHT, LIFT ARMED INDICATOR, 24V, GREEN
20 WASHER, FLAT, .406X.812X.065 (BAG OF 10)
21 TERM, SPL, M22-18 FULLINS, (BAG OF 10)
22 COUNTER ASSY
23 HYDRAULIC POPPET VALVE ASSY (DOWN VALVE), 12V
23A * HYDRAULIC POPPET VALVE ASSY (DOWN VALVE), 24V
24 HOSE CLAMP
25 RESERVOIR, PUMP, PLASTIC
26 PLUG, RESERVOIR, BREATHER
27 DECAL,OIL LEVEL WARNING
28 RESERVOIR, PUMP, PLASTIC W/DECAL & PLUG
29 CIRCUIT BREAKER, 30AMP, WHITE
30 DECAL, 30 AMP BREAKER, HYDRAULIC, PUMP ASSY
NOTE: (REF) in QTY column is for Referenced Parts Only and are not sold as spare parts.
NOTE: * Item or configuration not shown.
32DSSK06.D
K-SERIES PUBLIC USE SERVICE MANUAL
FIGURE 4-2: PUBLIC USE PUMP ASSY
(SUPERSEDED) SEE 5A
SPARE PARTS
QTY CONFIG. PART NO.
2 29297
1 10807
1 14345
1 42050
1 19067
1 45561
1 01176
1 01177
1 V2-SH-220
1 V2-SH-210
1 VS-SH-06
1 19798
1 V2-SH-005
1 10507
2 V2-SH-017
1 14332
1 18797
1 V2-ES-059
3 32407
1 V2-SH-012
1 UL-ES-034
1 V2-ES-016
1 17510
1 29388
1 33048
1 V2-SH-105
1 V2-SH-136
1 V2-SH-109
1 V2-SH-108
1 V2-SH-106
1 32-10-154
1 30938
1 26510
1 44270
4 - 5
