Wabtec RICON KlearVue K Series Service Manual page 48

DECEMBER 2018
FIG.
ITEM DESCRIPTION
1 HANDLE, MANUAL BACKUP PUMP
2 KIT, TOOL CLIP, W/HARDWARE
3 COVER, ASSY, PUMP, LH
3A * COVER, ASSY, PUMP, RH
4 SCREW, HEX, 5/16-18 X 5/8" GR 5 (BAG OF 10)
5 WASHER, FLT, .344 X .688 X .065 (BAG OF 10)
6 HEX ROD, PUMP STANDOFF
7 ** PUMP ASSY, W/O INTERLOCK, STD, DECEL VALVE, 12V, LH
7A ** PUMP ASSY, W/O INTERLOCK, STD, DECEL VALVE, 12V, RH
7B ** PUMP ASSY, W/O INTERLOCK, RAISED SCK, 12V, RH
7C ** PUMP ASSY, W/O INTERLOCK, RAISED, 12V, DECEL, LH
8 PLATE, PUMP COVER MOUNT
9 PLATE, PUMP MOUNT
10 SCREW, FLAT HEAD, 5/16-18 X 3/4" (BAG OF 10)
11 STUD, THREADED, 5/16-18 X 1.75" (BAG OF 10)
12 CABLE TIE, 5.5", BLACK (BAG OF 10)
13 TUBE, POLYURETHANE, 6MM x 4MM, BLACK
14 ADAPTOR, # 6 SAE MALE X # 4 JIC MALE
15 FITTING, "L", MALE 10-32 X 1/4", BARB
16 * KIT, CYL REPAIR (W/SEALS)
16A KIT, CYL REPAIR (PISTON/GLAND ASSY)
17 KIT, FLOW CONTROL, FIXED RATE .50 GPM (KIT OF 2)
18 SCREW, HEX RECESS HEAD, 1/4-20 X 1 (BAG OF 10)
19 HOSE ASSY, HYDRAULIC, 61" X 1/4 JIC X 1/4 JIC
19A * HOSE ASSY, HYDRAULIC, 64" X 1/4 JIC X 1/4 JIC
20 HOSE ASSY, HYDRAULIC, 26" X 1/4 JIC X 1/4 JIC
21 FITTING, RUN TEE, 1/4 JIC M-M-F
22 FITTING, "L", 1/4 JIC M-F SWIVEL
23 OIL, HYDRAULIC, TEXACO #15, MEETS MIL-H-5606G
24 CYLINDER ASSY 37", (BLACK)
CYLINDER ASSY 37", (BLACK)
CYLINDER ASSY 37", (BLACK)
24A * CYLINDER ASSY 43", (BLACK)
* CYLINDER ASSY 43", (BLACK)
* CYLINDER ASSY 43", (BLACK)
25 GROMMET, CATERPILLAR, 3/16" X 12"
26 SPACER, CABLE OR HOSE
27 BUSHING, 3/4"ID X 3/8W
NOTE: (REF) in QTY column is for Referenced Parts Only and are not sold as spare parts.
NOTE: * Item or configuration not shown.
NOTE: ** Refer to Pump Assembly figure for parts breakdown.
32DSSK06.D
K-SERIES PUBLIC USE SERVICE MANUAL
FIGURE 4-3: PUBLIC USE HYDRAULIC SYSTEM
(SUPERSEDED BY 21829)
SPARE PARTS
QTY CONFIG. PART NO.
1 V2-SH-111
2 19557
1 V2-CV-220
1 V2-CV-221
3 14495
3 13350
2 V2-CV-015
1 PM212200108
1 PM212200308
1 PM212100408
1 PM212100208
1 V2-AC-71
1 V2-AC-70
2 14499
2 14500
2 25697
9' 22-02-230
2 26591
2 V2-SH-16
2 V2-SH-56
2 21829
1 30968
4 14491
1 V2-SH-009
1 16601
1 V2-SH-008
1 V2-SH-012
3 VS-SH-06
1 GAL 20-16-051
2 K2003 VT-SH-105K
2 K2005 VT-SH-105K
2 K2010 VT-SH-105K
2 K5505 30836K
2 K5510 30836K
2 K5511 30836K
1 26647
2 25557
4 25386
4 - 7
