Wabtec RICON KlearVue K Series Service Manual page 58

DECEMBER 2018
FIGURE 4-6: PUBLIC USE FOLDING PLATFORM ASSEMBLY (CONT'D)
FIG.
ITEM DESCRIPTION
20 KIT, FLANGED BEARING, 1" ID (BAG OF 10)
21 BLOCK, PLATFORM LEVEL ADJUST
22 SCREW, BUTTON HEAD, 5/16-18 X 1/2, SST, BLK OXIDE (BAG OF 10) 1
23 SCREW, HEX HEAD, 5/16-18 X 1½, GR5 (BAG OF 10)
24 SETSCREW, ½-20 X 1/4, w/NYLON INSERT (BAG OF 10)
25 BUMPER, VHMW, .75D X .38T
26 SCREW, PAN HEAD, #8TEK X ½ (BAG OF 10)
27 SCREW, BUTTON HEAD, 5/16-18 X ¾ SST, BLK OX (BAG OF 10)
28 WASHER, FLAT, .28 X .63 X .06 (BAG OF 10)
29 BUSHING STEEL, .25ID X .32OD X.19L
30 SPACER, .25 ID X .40 OD X .20
30 SPACER, .25 ID X .40 OD X .20
30A SPACER, .25 ID X .40 OD X .38
SPACER, .25 ID X .40 OD X .38
SPACER, .25 ID X .40 OD X .38
SPACER, .25 ID X .40 OD X .38
31 NUT, w/NYLON INSERT, ¼-20 (BAG OF 10)
32 NUT, w/NYLON INSERT, 5/16-18, SST (BAG OF 10)
33 SCREW, HEX HEAD, ¼-20 X ¾ GR5 (BAG OF 10)
34 BUSHING, BRONZE
35 DECAL, REFLECTIVE, 3" X 24", RED & WHITE
35A DECAL, REFLECTIVE, 3" X 18", RED & WHITE
DECAL, REFLECTIVE, 3" X 18", RED & WHITE
DECAL, REFLECTIVE, 3" X 18", RED & WHITE
DECAL, REFLECTIVE, 3" X 18", RED & WHITE
DECAL, REFLECTIVE, 3" X 18", RED & WHITE
36 PLUG, MODIFIED, SQUARE
NOTE: (REF) in QTY column is for Referenced Parts Only and are not sold as spare parts.
NOTE: * Item or configuration not shown.
NOTE: ** SERIAL NUMBER BREAK E722039
32DSSK06.D
K-SERIES PUBLIC USE SERVICE MANUAL
SPARE PARTS
QTY CONFIG. PART NO.
1 19579
2 VT-AH-142
14484
1 14403
1 19704
2 V2-AC-027
1 15961
1 15983
1 17504
2 V2-BU-003
2 K2003 UV-PF-839
2 K5503 UV-PF-839
2 K5505 33805
2 K2010 33805
2 K5510 33805
2 K5511 33805
1 15919
1 14415
1 34518
2 V2-BU-195
2 K2003 33010
2 K2005 33011
2 K5505 33011
2 K2010 33011
2 K5510 33011
2 K5511 33011
1 32918
4 - 17
