The exhaust air can reach 65
or use forced air cooling themselves, increase the distances accordingly.
For ergonomic operation you can place the RCU on your desk, near to your transceiver. Please, have in
mind that the length of a connecting cable between ACOM 2020S and RCU R05 is 1.5 m.
Do not leave accidental paper, cloth or other lightweight pieces around and under the
amplifier. They may be drawn in by the cooling air stream and block the vents. This will
lead to overheating and accelerated material aging, not covered by the warranty.
June 2022
o o
C (150 F) and if the surrounding devices are sensitive to heating from outside

Figure 2-1 | RCU model R05 - Front panel with Touch screen

Figure 2-1 | RCU model R05 - Front panel with Touch screen

Figure 2-2 | Amplifier - Front view

Figure 2-2 | Amplifier - Front view
