c) AUTO OPERATE user settings
AUTO OPERATE user setting can be turned on/off by the operator in the USER PREFERENCES menu (see
Section
5.1 Menu USER PREFERENCES
command.
When the AUTO OPERATE user setting is OFF, the two modes OPERATE and STANDBY can be changed
alternatively by the OPR/STB button or by a remote control command. At a SOFT FAULT protection trip, the
amplifier will revert to STANDBY mode and wait for the operator to return it to OPERATE mode by pressing
the OPR/STB button.
When AUTO OPERATE is ON (see Section
OPERATE mode as soon as you turn it on. At a SOFT FAULT protection trip, the amplifier will also revert to
STANDBY mode, but will return automatically to OPERATE mode in about 4 seconds.
Even at AUTO OPERATE on, the operator can revert to and remain in a STANDBY mode manually by the
OPR/STB button or by a remote command. The next OPR/STB button push or remote command will switch
the amplifier to the OPERATE mode and restore the normal operation of the AUTO OPERATE user setting.

Band Change, Standard and Expanded Frequency Coverage

4.2.
When connected to a transceiver with CAT, the amplifier will change frequency bands automatically,
following the transceiver's operating frequency changes.
Without CAT connection, the bands can be changed either manually or automatically (by the built-in
frequency counter).
The bands are changed manually via the ten band-selection buttons (see
Section
3.5 Control System - Buttons and Menus
For an automatic band change via the built-in frequency counter, make a quite short pre-transmission
(100 ms is enough) and release the PTT for a moment before the main transmission.
If the new frequency is out of the amplifier's frequency range (see Section
transmission request will be denied and the following fault message will appear on the screen:
The amplifier specifications are guaranteed within the bands listed in Section
Frequency Coverage
June 2022
and
Figure 5-2 | Menu USER PREFERENCES
5.1 Menu USER PREFERENCES
, Point 2).
"FREQUENCY OUT OF RANGE"
.
) or by a remote control
), the amplifier will start up in
, Pos. 2 and
Figure 3-2 | Basic screen
8.1.a) Frequency Coverage
8.1.a)
S e c t i o n OPERATION | Page 39 of 76
), the
