6. REMOTE CONTROL

Remote control of ACOM 2020S is provided by either ACOM 2020S built-in Ethernet interfaces, or RS-232
interface.

Remote Control via Ethernet Interfaces

6.1.
Remote control of ACOM 2020S via Ethernet interface is provided by built-in:
Cable Ethernet interface (see
•
Wireless (Wi-Fi) Ethernet interface (see
•
When the amplifier is connected to your LAN network, its IP address (see
, Pos. 1) can be used to access its web-interface in an any web browser, running on a
in web browser on a PC
device (PC, smart phone, or tablet) connected to the same LAN network. The IP address of ACOM 2020S
can be seen and changed in the NETWORK SETTINGS menu (see
The amplifier's visualization through web-interface is identical to amplifier's "standard"
user interface when operated locally.
Through amplifier's web-interface you have a full access to all menus and functionalities
of ACOM 2020S.
1
Page 54 of 76 | S e c t i o n REMOTE CONTROL
Figure 2-6 | RCU model R05 rear panel

Figure 6-1 | Web-interface running in web browser on a PC

Figure 6-1 | Web-interface running in web browser on a PC
User's Manual | ACOM 2020S | 1.8-54 MHz Linear Power Amplifier
Figure 2-6 | RCU model R05 rear panel
Figure 6-1 | Web-interface running
5.6 Menu NETWORK SETTINGS
, Pos. 5);
, Pos. 6).
).
