h) The IEC 320-C20 (IEC 60320-C20) Power inlet
Please, see
Figure 2-3 | Amplifier rear panel - Connections
Due to the different standards in different countries, the mains plug for the amplifier power supply cable is
supplied and mounted by the dealer. He connects to the mains cord end a standard mains supply plug
which meets the Safety Class I unit standard in your country.
The power supply cable (a part of delivery) is in-factory assembled with power plug IEC 60320-C19 and with
free cable end at other side (3х2.5 mm², length 1.80 m (suitable cables are AWG 13 or SWG 15)).

2.4.2. Connections on RCU rear panel

6
8
i)
j)
i) AMPLIFIER connector
Please, see

Figure 2-6 | RCU model R05 rear panel

Connect the end of the ACOM 2020S to RCU connecting cable (part of delivery - see
as described in Section
2.4.1.f) RCU connector
Page 22 of 76 | S e c t i o n INSTALLATION
User's Manual | ACOM 2020S | 1.8-54 MHz Linear Power Amplifier
, Pos. (h).

Figure 2-5 | Power supply cable

Figure 2-5 | Power supply cable
Figure 2-6 | RCU model R05 rear panel
Figure 2-6 | RCU model R05 rear panel
, Pos. (i).
.
5
7
4
)
1.4 Equipment Supplied
June 2022
