1. General Information

1.1. Material Acceptance
Check that there is no damage on the packages during the transportation immediately after the material acceptance. If packages are
damaged, open the packages immediately and check whether products are affected or not, if there is any damage, send your
complaint report to the transporter company and its photocopy to the address of our company.
1.2. Information about Areas of Use
ISS Seviye sensörleri buhar kazanlarý su seviye kontrolü ve muhtelif iletken sývý tanklarý için ekonomik ve güvenli bir çözümdür.
Aplications Areas: Steam boilers , Degasifier , Condansate tanks , Conductive liquid tanks.
It should be used in allowed using medium and application areas!
It is not used in the corrosive mediums, ambient with explosive and flammable material.
Conformity with medium to be measured should be also taken into consideration.
Responsibility is not assumed in case of inappropriate use, modification and injure, and such cases are not covered by warranty.
Ambient Conditions: Relative Humidity: 5-95 %RH
1.3. Working Principle
ISS 04 Level Sensor is designed for controlling of conductive measurement principle. lt has four different measurement probe
and an electronic unit and so without any other control unit it allows to control by itself.
The sensor has two different conductive level measurement and four different control function, which are selectable by user.
lt can be used in min.1 µS/cm and over conductive liquids.
1.4. Features and Material Information
Technicial Specifications :
Mounting Position
Process Connections
Working Pressure
Case
Connection Material
Electrode Isolation
Electrode Material
Pipe Part
Pipe Material
Electrode Lenght
Electrode Diameter
Cable
Cable Entry
Supply
Electrode Voltage
Sensitivity
Output
Contact Current
Relay Delay
Ambient Temperature
Protection Class
Weight
Ambient temperature: 70 °C
Vertical (into boiler or with by-pass tube)
G 1”
32 Max. barg , Max. 238 °C
Aluminum Casting (Electrostatic Painted)
1.4571 Stainless Steel
PTFE
1.4571 Stainless Steel
PTFE
Stainless Steel
500 mm , 1000 mm , 1500 mm
4 mm
5 x 0.75 mm² With Silicon Ýsolated
3 pcs. PG 11 Chromed Brass
220-240 VAC (Std) or optional 24 VDC,2 VA
Max 6 V
1 uS/cm min. or 30 uS/cm min. selectable
Contact
4 x 8 A / 250 VAC
3 sec.
70 °C
IP 65
2,9 kg ( For L: 1000mm)
(It is not used under -5 °C)
Avantages :
* Compact structure.
* Multi-function can be controlled.
* Wetted parts is 316 stainless steel.
* Low conductivity liquids can be worked.
1.5. Label Information
Product Label :
Manufacturer Brand
Model
Type :
Serial
S.N. :
Number
MADE IN TURKIYE
2
Product Name Approval Sign
LEVEL SENSORS
ISS 04 - 0 - 002 - 57 - 00 - 066 - 1000 - 11 - 4/0
18040263-0006
www.ensim.com.tr
Manufacturer
Website
Warning
Symbols
