ENSIM SENSORS ISS 04 Operating Manual page 4

Components
Terminal Box (E.Card Case)
1
Heat insulating Lag
2
Connection Screw
3
Joint Ring (Copper or Aluminium)
4
Electrode Rods
5
Fixing Nut
6
Electrode Tips Connection Headers
B1
S1- Configuration Switch
B2
S2- Sensitivity Switch
B3
Indicator LEDs
B4
Terminal Strip
B5
Cable Glands (3xPg11)
B6
Fieldbus Add-On Card Connection Header (Option!.)
01
CanOpen Terminal (Option!.)
02
Fieldbus Line Cable Gland (Option!.)
03
Hole for Add-On Card Fixing screw.
04
4
Figure 1
