Replacing the Power Supply
Replacing the Power Supply
To remove the old power supply, loosen the captive screw and slide the
power supply out of the chassis, as shown in Figure 15.
Figure 15
Removing the Power Supply
To install the new power supply, slide the power supply into the chassis and
tighten the captive screw as shown in Figure 15.
23
