Installation Prerequisites

Installation Prerequisites
Before the Model C100/C110/C160/C180 to a Model C200 Upgrade can be
performed, the current system must have an operating system version HP-
UX 10.20 or greater. The graphics card option being moved to the new
system must also be on the supported list of cards. If it is not, use the builtin
EG graphics or upgrade the graphics card option to a supported
configuration as outlined in the graphics option table below

Operating System

Verify that the HP-UX operating system is at a minimum level of 10.20. This
software must be loaded on the system before performing this upgrade.
Graphics Card Support
Verify that the graphics card(s) installed in your Model C100/C110/C160/
C180 are supported on the Model C200. The /usr/bin/graphinfo command
will display the current graphics card(s) information. Both HCRX8 and
HCRX24 cards require a physical inspection of the card to verify the Z-
Accelerator part number. The first 5 alpha-numeric characters on the Z
Accelerators white label must read A4242. The Z-Accelerator is the small
daughter card. If a graphics upgrade is required, it should be performed prior
to performing this upgrade.
The following table presents the graphics options that are supported and
NOT supported or recognized under HP-UX 10.20.
Table 1 Graphics Options Supported and Not Supported Under HP-UX 10.20
2
Graphic Options Supported
VIZUALIZE-8, 24, 48, 48XP
VIZUALIZE EG, Dual EG
A4070A/B + A4242A (HCRX-8Z
with the A4443A Upgrade)
A4071A/B + A4242A (HCRX-24Z
with the A4443A Upgrade)
Graphic Options NOT Supported
Color - A4077A
Dual Color - A4078A
A4071B HCRX-24 with the A4072A Z
Accelerator
