Installing Option Boards
6 Slide the option board into the slot. Make sure that the hole in the board's handle
Figure 12
7 Press in firmly on both ends of the option board at the same time to make sure
20
aligns with the pin on the back panel, as shown in Figure 12.
Installing an Option Board
that it is firmly seated in the backplane connector.
