4 In the desired option slot, turn the blank plate's locking knob counter-clockwise

NOTE:

The new main tray assembly contains a blank plate which is held in by a locking

knob. Be sure to remove these components before attempting to install the option

boards.

Figure 11

5 Remove the blank plate from the slot, as shown in Figure 11.

to unlock the plate, as shown in Figure 11.

Removing a Blank Plate

Installing Option Boards

Locking Knob

Blank Plate

EISA Slider
