Wiring Diagram - Directed Directechs DB3 Installation Manual

Wiring diagram

Refer to "Pre-installation and application warnings" for important information, such as the description of each special note referenced in the diagram (
D2D Port
(-) Hood Pin Input
(-) Ground
(+) Ignition Input/Output
(+) 12V Input
IGPM Plug (A)
(black connector
in dash fuse box)
1 2 3 4
(+) 12V: Red, pin 1
6 403.HKRS03 1.02 2021 Kia K5 2.5L Turbo (Smart Key)
©2021 VOXX•DEI LLC. All rights reserved.
B-C AN Low:
Orange, pin 13
IGPM Plug (G)
1
(white 16-pin conn.
1314
9
rear dash fuse box)
M-C AN Low:
Black, pin 15
Hood Pin
B-C AN High:
Green, pin 14
8
15 16
16
M-C AN High:
Yellow, pin 16
HS CAN 2 High: Tan/Black: 3
HS CAN 4 High: Orange/Green: 5
HS CAN 4 Low: Orange/Brown: 6
(+) Ignition Status Output: Gray/Black: 7
HS CAN 2 Low: Tan: 4
).
XKD2D65
