Module programming

Refer to "LED diagnostics and troubleshooting" for more information and for troubleshooting purposes.
Connect the 10-pin, 12-pin, and 14-pin harnesses to DB3 and wait until the LED turns
1
ON solid red.
Press the PTS button twice to turn the ignition ON.
2
The LED will flash green quickly.
3
Wait for the LED will turn on solid green for 3 seconds and then turn off.
You have successfully completed the module programming sequence.
10
403.HKRS03 1.02 2021 Kia K5 2.5L Turbo (Smart Key)
