Contents
Important User Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Manufacturer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Intended Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Set Up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Take Down . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Lock Units Together . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Reverse Step Arrangement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Attach an Optional 4th-Step Addition . . . . . . . . . . . . . . . . . . . . . . 9
Attach an Optional Back Rail . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Visit the Tourmaster Choral Risers web page at wengercorp.com for more information.
Note: Please read and understand these instructions before working with the riser.
Note: If you need additional information, contact Wenger Corporation using the information below.
©Wenger Corporation 2022
Wenger Corporation, 555 Park Drive, P.O. Box 448, Owatonna, Minnesota 55060-0448
USA: (800) 4WENGER (493-6437) • Worldwide: +1-507-455-4100 • wengercorp.com
Tourmaster
Series 024H 3-Step with Foot Operated Slider
Store an Optional Back Rail . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Attach Optional Side Rails . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Store Back Rails on Optional Riser Cart . . . . . . . . . . . . . . . . . . . . 15
Store Risers on Optional Riser Cart . . . . . . . . . . . . . . . . . . . . . . . 18
Store 4th-Steps on Optional Riser Cart . . . . . . . . . . . . . . . . . . . . 22
Replacement Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Printed in USA 2022-04
Choral Riser
™
Shown with Optional
Basic 3-Step Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
4th-Step Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Back Rail . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Side Rails . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Riser Cart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Owner's Manual
Backrail
Part #024H636-04
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Wenger Tourmaster Choral Riser
Summary of Contents for Wenger Tourmaster Choral Riser
-
Page 1: Table Of Contents
Visit the Tourmaster Choral Risers web page at wengercorp.com for more information. Note: Please read and understand these instructions before working with the riser. Note: If you need additional information, contact Wenger Corporation using the information below. ©Wenger Corporation 2022... -
Page 2: Important User Information
Wenger Corporation. Wenger Corporation does not assume any responsibility for any errors that may appear in these instructions. In no event will Wenger Corporation be liable for technical or editorial omissions made herein, nor for direct, indirect, special, incidental, or consequential damages resulting from the use or defect of these instructions. -
Page 3: Safety Precautions
Read all of these safety instructions before assembling or using the equipment. CAUTION CAUTION Make sure that anyone working Failure to comply with Warnings on the Tourmaster Choral Riser and Cautions in this document has read and understands these can result in damage to property instructions. -
Page 4: Set Up
Set Up CAUTION Set up and use the riser only on a FLAT SOLID surface. 1. Roll the riser (push or pull it) to the 2. Grasp the side of the top step. performance or rehearsal area. 3. Unfold. 4. Lay the riser flat on the floor, carpet-side up. - Page 5 Set Up (continued) 5. Grasp the end of the top step at the "hand position" decals, and place your right foot on the riser leg decal. WARNING To avoid injury, grasp ends of top step only at "hand position" decals. 6.
-
Page 6: Take Down
Take Down 1. Kick the latch release forward, and at the same time press down the latch lever with your foot. 2. Grasp the end of the top step at the "hand position" decals, and lower the unit flat on the floor. CAUTION WARNING The unit will drop to the... -
Page 7: Lock Units Together
Lock Units Together 1. Before you lock any units together, set up all units and move them into position next to each other. To move a 3-step riser, lift the 1st step and roll the unit on its two positioning wheels. With 3-step risers, also attach any back rails and 4th-step options (see pages 10-11). -
Page 8: Reverse Step Arrangement With Optional 4Th-Step Addition
Reverse Step Arrangement with Optional 4th-Step Addition 1. Take off the first and fourth steps by loosening the capscrews that hold the steps to the legs. Don't loosen the second or third steps capscrews yet. 2. Turn the first and fourth steps end-for-end, and switch their places as shown. Reattach the steps to the legs. -
Page 9: Attach An Optional 4Th-Step Addition
Attach an Optional 4th-Step Addition 1. If the riser has a back rail installed, remove it before attaching the 4th-step. 2. Open both locking clamps on the 4th-step. 3. Position the 4th-steps brace brackets to the right side (viewed from the rear) of the risers leg assemblies. On the right side, place the bracket between the leg and the positioning wheel. -
Page 10: Attach An Optional Back Rail
Attach an Optional Back Rail Note: Back rails (optional) are recommended on all risers. 1. Open the locking clamps on the lower posts of the back rail. Note: In the following steps, install the lower posts so their wheels are on the inside (facing each other). 2. -
Page 11: Store An Optional Back Rail
Store an Optional Back Rail 1. Open the locking clamps, and move the back rail away from the riser. For storage, turn the rail 90° and lean it against the wall (setting on its side). 2. (Optional — provides more compact storage) Press the snap buttons and remove the lower posts from the rail. -
Page 12: Attach Optional Side Rails
Attach Optional Side Rails Note: Back Rails are required in order to attach side rails. 1. Place the side rail in the approximate attachment position with the leg extension resting on the floor. Slide the side rail towards the back rail until the side rail bracket fits over the back rail as shown below. Back Rail Side Rail Back Rail... - Page 13 Attach Optional Side Rails (continued) 2. Rotate the upper and lower swing brackets to a vertical Back Rail position, locking the side rail to the back rail. Side Rail Upper Swing Bracket Lower Swing Bracket 3. Lift and hold the front of the riser off the floor and slide the lower leg cradle bracket under the step support frame.
- Page 14 Attach Optional Side Rails (continued) 4. A rail lock down bracket is used to reduce movement of the back rail when using the side rail. Thread the right and left hooks into the turnbuckle. Engage the back rail and top step with the rail lock down bracket hooks as shown below.
-
Page 15: Store Back Rails On Optional Riser Cart
Store Back Rails on Optional Riser Cart Load up to four back rails onto a riser cart as follows. 1. Lift a back rail with the positioning wheels on the legs pointing upward and the legs next to the cart (horizontal rail is away from the cart). - Page 16 Store Back Rails on Optional Riser Cart (continued) 3. To load the second back rail, lift it with the positioning wheels on the legs pointing upward and the back rail legs facing away from the cart. 4. Place the back rail onto the back rail supports with the back rail horizontal rails touching as shown below. Note: Each pair of back rails can be loaded onto the cart with either the horizontal rail touching or the back rail legs nested together.
- Page 17 Store Back Rails on Optional Riser Cart (continued) 5. Place the third and fourth back rails onto the cart with the horizontal rails touching as shown below. Horizontal Rails Riser Cart Cart loaded with tour Back Rails Vertical Legs Third Back Rail Second Back Rail Fourth Back Rail Third Back Rail...
-
Page 18: Store Risers On Optional Riser Cart
Store Risers on Optional Riser Cart Load up to four risers onto the riser cart as follows. 1. Begin opening the swing arms by pushing upward on the under side of the swing arm horizontal bar as close to the swing arm post as possible. Always start with the highest arm and swing the arm away from the cart. Loaded back rails are not Swing Arm shown for clarity. - Page 19 Store Risers on Optional Riser Cart (continued) 3. With two people working together, place the first riser onto the cart. The positioning wheels will hang over the right end of the cart support frame. Note: The 13-inch swing arm must be on the right side of the cart. If the 13-inch swing arm is not on the right side of the cart, it is assembled incorrectly.
- Page 20 Store Risers on Optional Riser Cart (continued) 5. With two people working together, place the second riser onto the cart with the positioning wheels on the left end, opposite from the first riser positioning wheels. Make sure that the positioning wheels hang outside of the swing arm.
- Page 21 Store Risers on Optional Riser Cart (continued) 7. With two people working together, place the third and fourth risers onto the cart (as in steps 2 to 6 above) with the positioning wheels alternating as shown below. Make sure that the positioning wheels hang outside of the swing arm.
-
Page 22: Store 4Th-Steps On Optional Riser Cart
Store 4th-Steps on Optional Riser Cart 1. Place the first 4th-step onto the top set of swing arms with the carpet side down and the positioning wheels facing outward (away from the swing arm post). 2. Place the second 4th-step with the carpet side up with the positioning wheels facing outward. 3. -
Page 23: Replacement Parts List
Replacement Parts List Basic 3-Step Unit 20 19 9 10 21 22 27 27 26 26 26 26 24 24 25 25 20 23 30 27 27 27 27 14 17 20 20 Item Qty Description Item Qty Description Step Assembly, 1st Carriage Bolt, 5/16-18 x 1-1/2"... -
Page 24: 4Th-Step Unit
Replacement Parts List (continued) 4th-Step Unit When ordering replacement parts for a 4th-step unit, you will need to know if steps are 18 inches or 24 inches deep. Item Qty Description Item Qty Description Step Assembly, 4th Bolt, Carriage, 5/16-18 x 1-1/4" Leg Assembly, 4th Clamp Assembly, Unit-to-Unit Support, Leg... -
Page 25: Back Rail
Replacement Parts List (continued) Back Rail Item Qty Description Item Qty Description Post, Lower Nut, Lock, 5/16-18 x 1-3/4" Rail Assembly Capscrew, 5/16-18 x 1-3/4" Bracket, Back Rail Plug, Square Clamp, Locking Wheel, Positioning, 2" Plug, Rectangular Nut, 5/16-18 Washer, Flat, 5/16" Capscrew, 5/16-18 x 2-1/4"... -
Page 26: Side Rails
Replacement Parts List (continued) Side Rails Item Qty* Description Item Qty* Description Side Rail Bracket Side Rail Capscrew, 5/16-18x2" Capscrew, 5/16-18x1-3/4" Swing Bracket Side Rail Leg Flat Washer, 5/16" Plug, Square, 1-1/4" Locknut, 5/16-18 Slide Leg * Quantity is for a set of side rails. -
Page 27: Riser Cart
Replacement Parts List Riser Cart Item Qty Description Item Qty Description Hex Head Cap Screw, 3/8-16x2-1/2" Swing Arm, 10-inch Hex Head Cap Screw, 3/8-16 x 1" Riser Cart Frame Hex Head Lock Nut, 3/8-16 Caster Cross Bar Back Rail Support Post Swing Arm Post Safety Strap (not shown) Swing Arm, 13-inch... -
Page 28: Troubleshooting
Troubleshooting Stiff Operation (hard to set up or take down) Spray the pivot points and slide with a nonstaining lubricant like WD-40 ® Carpet "Balls Up" Normal with a new carpet. Vacuum periodically. Wheel Doesn't Turn Freely Loosen the bolt just enough for free turning. Riser "Rattles"...
