C
ONTENTS
Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Important User Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Required Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Upgrade Description. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Upgrade Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Floor Level Closures . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Elevation Closures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Assembly Instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Riser Assembly. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Floor-Level Closure Assembly . . . . . . . . . . . . . . . . . . . . . 8
Elevation Closure Assembly. . . . . . . . . . . . . . . . . . . . . . . 8
This publication includes upgrade instructions for the Trouper Platform System.
Please take a few minutes to read and understand these instructions. If you should need additional
information, just write or call.
For more detailed assembly, installation and owners instructions, see the "Trouper and Stagehand
Platform Systems Owner's Manual" Part #176A700.
©Wenger Corporation 2005
Wenger Corporation, 555 Park Drive, P.O. Box 448, Owatonna, Minnesota 55060-0448
Questions? Call.....USA: (800) 733-0393 • International (call collect): (507) 455-4100 • www.wengercorp.com
Trouper
Printed in USA 09/05
Upgrade Instructions
™
Closure Panels
Part #176A711-01
Advertisement
Table of Contents
Related Manuals for Wenger Trouper
Summary of Contents for Wenger Trouper
- Page 1 Please take a few minutes to read and understand these instructions. If you should need additional information, just write or call. For more detailed assembly, installation and owners instructions, see the “Trouper and Stagehand Platform Systems Owner’s Manual” Part #176A700.
- Page 2 Trouper units unless adequate special clamping is provided to secure the levels together. See “Riser Assembly” on page 6 for more information. Trouper platforms are designed for level surfaces only and contain no provision for adjusting leg heights. WARNING...
- Page 3 EQUIRED OOLS The following tools must be available to upgrade the Trouper Closure Panel system: Phillips Head Screwdriver 3/8 “ Combination Wrench or Ratchet with 3/8 Socket PGRADE ESCRIPTION The components provided for the Trouper Closure Panel upgrade includes: •...
- Page 4 PGRADE NSTRUCTIONS LOOR EVEL LOSURES 1. Remove all floor-level closure panels from the riser set (if riser set is assembled). 3. Replace the clips on the front and side floor level closures: a. Use a 3/8” wrench or ratchet to loosen the nut. b.
- Page 5 PGRADE NSTRUCTIONS ( CONTINUED LEVATION LOSURES 1. Remove all elevation closure panels from the riser set (if riser set is assembled). 2. Discard all of the existing loose lower clips. 3. Replace any damaged or broken positioning brackets: a. Use a Phillips Head screwdriver to remove the screw attatching the bracket to the clousure panel.
- Page 6 SSEMBLY NSTRUCTIONS ISER SSEMBLY 1. Disassemble the rest of the riser set. a. Detach all unit to unit connectors from adjacent staging units. Remove all metal spacer brackets connecting the leg assembly and set aside. 2. Set up the back row of platforms (including any rear extensions), to verify that there is enough space for the full riser set.
- Page 7 SSEMBLY NSTRUCTIONS ( CONTINUED 6. Align the edges of the pie-shaped units vertically. Make sure the corners of the decks are aligned. Align the edges 7. Connect all matching height units together using the unit-to-unit clamps. 8. Connect different height pie-shaped units together using the existing metal spacer assemblies.
- Page 8 SSEMBLY NSTRUCTIONS ( CONTINUED LOOR EVEL LOSURE SSEMBLY 1. Place interlocking leg spacers on the floor under the inside legs of the front row of the rectangular units as shown in the illustration. Platform legs fit into the hole in the center of the spacer. This provides a backstop for the front floor closure panels.
