Enviro E44I Owner's Manual

Gas insert - log set w/ ipi valve

Hide thumbs Also See for E44I:

Owner's manual (45 pages)

Table Of Contents

Table of Contents

Quick Links

Download this manual

E44I / E44ID

G A S I N S E R T - L O G S E T w / I P I V a l v e

OWNER'S MANUAL

WARNING:

If the information in this manual is not followed exactly,

a fire or explosion may result causing property damage, personal

injury or loss of life. Installation and service must be performed by a

qualified installer, service agency or the gas supplier.

C#4001609

CERTIFIED TO/CERTIFIÉ AUX: ANSI Z21.88 / CSA2.33 / CSA 2.17

50-2628

Version Française: www.enviro.com/fr.html

Table of Contents

Need help?

Do you have a question about the E44I and is the answer not in the manual?

Questions and answers

Terry Leighton

April 6, 2025

My remote says fireplace is set on ISI but ilot light is still lit

1 comments:

Mr. Anderson

April 6, 2025

The pilot light may still be lit because the fireplace is set to Continuous Pilot Ignition (CPI) mode, not Intermittent Pilot Ignition (IPI). If CPI was selected using the remote, the pilot remains on even when the fireplace burner is off. To switch back to IPI, press the mode key to select the pilot icon, then press the down arrow key. The IFC will beep once to confirm the change.

This answer is automatically generated

Summary of Contents for Enviro E44I

Page 1 E44I / E44ID G A S I N S E R T - L O G S E T w / I P I V a l v e OWNER’S MANUAL WARNING: If the information in this manual is not followed exactly, a fire or explosion may result causing property damage, personal injury or loss of life.
Page 2: Safety Precautions
Safety Precautions WARNING: FIRE OR EXPLOSION HAZARD Failure to follow safety warnings exactly could result in serious injury, death, or property damage. - Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance. - WHAT TO DO IF YOU SMELL GAS •...
Page 3 Safety Precautions FOR SAFE INSTALLATION AND OPERATION OF YOUR “ENVIRO” HEATER, PLEASE CAREFULLY READ THE FOLLOWING INFORMATION: • All ENVIRO gas-fired appliances must be installed in • A barrier designed to reduce the risk of burns from the accordance with their instructions. Carefully read all the hot veiwing glass is provided with this appliance and shall instructions in this manual first.
Page 4: Table Of Contents
Table of Contents Safety Precautions �� 2 Table of Contents �� 4 Codes And Approvals �� 6 Specifications �� 7 Rating Label Location: ........................7 Dimensions: ..........................7 Install Depth: ..........................7 Operating Instructions �� 9 Lighting and Turning Off Instructions: ..................... 9 Venturi Adjustment: ........................10 Remote Control Operations: ......................10 System Description: ........................11...
Page 5 Table of Contents Surround Panel Installation: ......................34 Firebox Liner and Burner Tube Removal: ..................35 Log Set and Ember Installation (Traditional & Birch): ...............36 TroubleShooting �� 40 Diagnostic Flash Codes (does not apply to E44ID models): ..............40 Parts List �� 43 Parts Diagram - Components ��...
Page 6: Codes And Approvals
After the unit has gone through the first burn, turn the unit off, let the unit get cold then remove the glass door and clean it with a good gas fireplace glass cleaner, available at your local ENVIRO dealer. See “D ”...
Page 7: Specifications
Specifications ating abeL ocation The rating label is located on the left side of the unit, next to the receiver box. imensions 34.19 24.51 10.09 10.42 17.76 14.98 *Shown with Borderview surround panel & Base Shelf* 45.00 38.25 31.03 29.33 28.75 31.04 25.38...
Page 8 Specifications 45” 30 ⁄ ” 32 ⁄ ” 46 ⁄ ” Figure 2: E44 Contemporary Surround with Base Shelf and Riser. Table 2: E44 Options Dimensions. Regular Surround Contemporary Surround Extruded Surround Height ” (765 mm) ” (765 mm) ” (765 mm) Width 45”...
Page 9: Operating Instructions
Operating Instructions For Your Safety, Read Safety Precautions And Lighting Instructions Before Operating WARNING: IF YOU DO NOT FOLLOW THESE INSTRUCTIONS EXACTLY A FIRE OR EXPLOSION MAY RESULT, CAUSING PROPERTY DAMAGE, PERSONAL INJURY OR LOSS OF LIFE� ighting anD uRning nstRuctions FOR YOUR SAFETY READ BEFORE OPERATING WARNING:...
Page 10: Venturi Adjustment
Operating Instructions entuRi Djustment The venturi adjustment lever is located on the right side of the unit, below the door (see Figure 4). To avoid touching hot surfaces under the unit, use the Door Tool to adjust the venturi. The venturi allows the amount of air coming into the fireplace to be adjusted in order to accommodate different climates and venting arrangements.
Page 11: System Description
Operating Instructions For E44ID models refer to the separate Dexen user manual supplied for remote control operations. ystem escRiption The Proflame 2 Remote Control System consists of two (2) elements: 1. Proflame 2 Transmitter. 2. Integrated Fireplace Controller (IFC) and wiring harness to connect to the gas valve, stepper motor battery holder, and convection fan.
Page 12: Battery Holder
Operating Instructions Key Lock Transmission Low battery alarm Thermostat OFF/ Room ON/SMART Temperature CPI mode Set Point Aux ON Temperature/Level/State ot used Flame ON Split Flow ot used Dimmer ON Comfort fan ot used Figure 6: Proflame 2 Transmitter LCD Screen. atteRy oLDeR The Battery Holder (Figure 7) connects directly to the IFC with a wiring harness.
Page 13: Operating Procedure
Operating Instructions peRating RoceDuRe Initializing The System For The First Time Install the four (4) AA batteries into the IFC battery holder. Note the polarity of the battery and insert into the battery bay as indicated on the body of the battery holder. Press and release the reset button (see Figure 7). The IFC will “beep”...
Page 14 Operating Instructions Remote Flame Control The Proflame 2 GTMF has six (6) flame levels. With the system on, and the flame level at the maximum in the appliance, pressing the Down Arrow Key once will reduce the flame height by one step until the flame is turned off. The Up Arrow Key will increase the flame height each time it is pressed.
Page 15 Operating Instructions Split Flow Control This function is not used on the E44 and can be disregarded. Figure 14: Split Flow Control Aux Control This function is not used on the E44 and can be disregarded. Figure 15: Aux Control Key lock This function will lock the keys to avoid unsupervised operation.
Page 16 Operating Instructions Low Battery Power Detection Transmitter: The life span of the remote control batteries depends on various factors: quality of the batteries used, the number of ignitions of the appliance, the number of changes to the room thermostat set point, etc. When the Transmitter batteries are low, a Battery Icon will appear on the LCD display of the Transmitter (see Figure 17) before all battery power is lost.
Page 17: Maintenance And Service
Maintenance And Service Warning: Failure to position the parts in accordance with this manual, or failure to use only parts specifically approved with this appliance, may result in property damage or personal injury. At least once a year, run through the following procedures to ensure the system is clean and working properly.
Page 18: Removing Valve Cover
The glass must be purchased from an ENVIRO dealer. No substitute materials are allowed. Remove the door (see page 16). The replacement glass will come with a new gasket installed. Remove any silicone remnants from the door.
Page 19: Fuel Conversion
The installation is not proper or complete until the operation of the converted appliance is checked as specified in the manufacturer’s instructions supplied with the kit. Kit Parts List for all E44I models: 1 - Orifice (NG: #31) or (LP: #50) 1 - Servo Regulator with diaphragm...
Page 20 Maintenance And Service 7. Convert the SIT gas valve: a) Use a T-20 driver to remove the two screws that hold the servo regulator to the gas valve and disconnect the wire harness from the IFC. b) Remove the rubber regulator diaphragm that is situated between the servo regulator and the valve body.
Page 21: Initial Installation
The E44I / E44ID may be installed and vented into any solid fuel fireplace that has been installed in accordance with the National, Provincial/State and local building codes and has been constructed of noncombustible materials. Before starting, refer to please reference the information in Table 5 and Figures 26 and 27.
Page 22: Venting
Initial Installation Non-Combustible Facing Material Only Non-Combustible Framing i�e� steel stud All Sides of Build Out Sealed off Surround Panel Finished Opening Dimensions (H x W) = Surround Panel - Desired Overlap Figure 25: Installation with a non-combustible build out� enting WARNING: This appliance has been designed to draw room air for proper heat circulation from the sides and bottom of the unit, and out the top front.
Page 23 Initial Installation QUALIFIED INSTALLERS ONLY The ENVIRO E44 may be installed and vented into any solid fuel fireplace that has been installed in accordance with the National, Provincial/State and local building codes and has been constructed of non- combustible materials. Before starting, refer to please reference the information in Table 5 and Figures 26 &...
Page 24: Baffle Plate Adjustment
Make sure that all chimney cleanouts are tight fitting and will not permit air to leak into the chimney. Initial Installation Refractory, glass doors, screen rails, screen mesh and log grates can be removed from the fireplace before installing the unit. QUALIFIED INSTALLERS ONLY The height for the vent must be between 10 ft (3.05 m) and 40 ft (12 m) from the top of the unit to the bottom of the termination...
Page 25: Installing The Unit
Initial Installation QUALIFIED INSTALLERS ONLY Figure 29: Baffle plate adjustment Figure 28: Baffle plate screws nstaLLing the • Remove the packaging from the appliance and check to make sure there is no damage. Carefully check the glass door. Do not use the unit if it is damaged. In the event damage is found, please report it to your dealer as soon as possible.
Page 26 Initial Installation QUALIFIED INSTALLERS ONLY Table 5: Vent termination clearances Minimum Clearance* Description Clearance above the highest point where it passes through a roof surface, refer to 3 ft (0.9 m) Figure 30. Clearance above a roof ridge, any other portion of a building, or any other obstruc- 24 in (0.6 m) tion within a horizontal distance of 10 feet (3 m), refer to Figure 30.
Page 27: Zero Clearance (Zc) Fireplace Installation
Initial Installation QUALIFIED INSTALLERS ONLY 12. Place a bead of high temperature silicone on Vent Collar Screw the intake collar of the fireplace, slide the Ø3” (76mm) flex intake liner over the collar, secure the flex liner with three (3) sheet metal screws evenly spaced.
Page 28: Electrical Requirements
Initial Installation QUALIFIED INSTALLERS ONLY LectRicaL equiRements The fireplace must be electrically connected and grounded in accordance with local codes or, in the absence of local codes, with the current CSA C22.1 Canadian Electrical Code Part 1, Safety Standards For Electrical Installations, or The National Electrical Code ANSI / NFPA 70 in the US.
Page 29: Gas Line Connection
½ psig (3.45 KPa) or the valve will be damaged. Figure 36: Gas valve with cover removed Table 7: Orifice and Pressure Information. E44I With Log Set Main Burner Natural Gas Propane Gas Orifice: #31 DMS #50 DMS Max.
Page 30: Adjusting The Pilot Flame (Does Not Apply To E44Id Models)
Initial Installation QUALIFIED INSTALLERS ONLY TO TEST VALVE PRESSURES (INPUT RATES): The pressure taps are located on the front side of the valve (see Figure 37). 1. Using a long flat bladed screwdriver, turn set screw one (1) turn counter-clockwise to loosen. 2.
Page 31: Secondary Installation
Secondary Installation & R ptionaL heLf iseR The E44 Base Shelf (1⅝” (41 mm) high) and Base Shelf Riser (2⅛” (54 mm) high) are components that can be combined to create a riser with an overall height of 2 ” (55 mm). This shelf can be installed with or without the riser and can be used when the hearth in front of the unit is lower than the fireplace opening.
Page 32: Optional Trimmable Panels
Secondary Installation ptionaL RimmabLe aneLs Modifying the Surround Panel: The E44 Trimmable Surround Panels are large rectangular panels that may be cut for use in cases that a non- standard fireplace opening (e.g. an arched opening) is to be filled. Optionally this surround can be left uncut and placed in front of the fireplace opening.
Page 33: Extension Setting 1
Secondary Installation xtension etting The E44 is shipped with the cabinet extensions in Setting 1. This setting is used for the Contemporary Surround Panel, Extruded Surround Panel, and Borderview Surround Panel. These panels can be attached to the unit without any changes. xtension etting The Cape Cod Surround Panel and Modern Surround Panel will need to be installed with the cabinet extensions...
Page 34: Surround Panel Installation
Secondary Installation uRRounD aneL nstaLLation WARNING: The surround becomes hot when the unit is operating; ensure that the unit is turned off, and that it has cooled to room temperature before beginning this installation. Height Width 3-Sided Surround ” (765 mm) 45”...
Page 35: Firebox Liner And Burner Tube Removal
Secondary Installation iRebox ineR anD uRneR emoVaL NOTE: The firebox liners are fragile and should be handled gently. 1. Ensure the E44 is turned off and allow the unit to cool. 2. Remove the glass door as shown in the m aIntenanCe anD erVICe lass...
Page 36: Log Set And Ember Installation (Traditional & Birch)
Secondary Installation & b et anD mbeR nstaLLation RaDitionaL iRch NOTE: The logs are fragile and should be handled gently. WARNING: Failure to position the parts in accordance with these diagrams or failure to use only parts specifically approved with this appliance may result in property damage or personal injury.
Page 37 Secondary Installation Figure 56: Install the right top log on top of rear log and right mid log. Locate the bottom on the far right grate arm. Figure 57: Break up the ember wool as fine as possible (clump the wool together and separate it using the supplied brush) over the burner tube.
Page 38 Secondary Installation Figure 59: Rest the center top log on top of the left mid log making sure to align the bottom with grate arm. Figure 60: Place the center front chunk log on the log grate, close to the center, with the front edge resting on the right mid log.
Page 39 A small amount on the bottom side of the logs is normal. Remove and replace the logs in the same manner described above. If new logs are required, contact your nearest ENVIRO dealer. Never operate the fireplace with the glass door removed.
Page 40: Troubleshooting
TroubleShooting e44iD iagnostic Lash oDes Does not appLy to moDeLs 1. Fail to ignite: If there is no positive ignition, the board will go into lock out and the LED will blink 3 times in intervals until the system is reset. 2.
Page 41 Trouble Shooting Note: For E44ID specific troubleshooting refer to the Dexen user manual supplied Problem Possible Cause Solution The pilot flame has gone out · Turn it ON Thermostat The On/Off switch is turn to OFF does not work The thermostat is set too high ·...
Page 42 Trouble Shooting Problem Possible Cause Solution · Turn the system off by pressing the ON/OFF button on the transmitter · After approximately 2 seconds press the ON/OFF button on the transmitter again. · In the manual flame control mode, use the down arrow button to reduce the flame to off, indicated by the word OFF displayed on the transmitter LCD screen.
Page 43: Parts List
Note: For E44ID specific replacement parts refer to the Dexen user manual supplied Reference Part Description Part Number Number E44 DV Flue Adaptor Bottom Gasket 50-2516 E44I Owner’s Manual 50-2628 IPI LP Conversion Stepper Motor Only 50-3753 IPI NG Conversion Stepper Motor Only 50-3870 Door Release Tool...
Page 44: Parts Diagram - Components
Parts Diagram - Components...
Page 45 Notes...
Page 46: Installation Data Sheet
Sherwood Industries Ltd. (“Sherwood”) hereby warrants, subject to the terms and conditions herein set forth, this product against defects in material and workmanship An expanded list of exclusions is available at www.enviro.com/help/warranty.html during the specified warranty period starting from the date of original purchase at retail.
Page 47 Installation Data Sheet The following information must be recorded by the installer for warranty purposes and future reference. NAME OF OWNER: NAME OF DEALER: _________________________________________ _________________________________________ ADDRESS: ADDRESS: _________________________________________ _________________________________________ _________________________________________ _________________________________________ _________________________________________ _________________________________________ PHONE:___________________________________ PHONE:___________________________________ NAME OF INSTALLER: MODEL:___________________________________ SERIAL NUMBER:___________________________ _________________________________________ DATE OF PURCHASE: _____________...
Page 48 MANUFACTURED BY: SHERWOOD INDUSTRIES LTD. 6782 OLDFIELD RD. SAANICHTON, BC, CANADA V8M 2A3 www.enviro.com May, 2022 C-15553...
