E33I
GAS INSERT
LOG SET & PROFLAME IPI VALVE
OWNER'S MANUAL
WARNING:
If the information in this manual is not followed
exactly, a fire or explosion may result causing property damage,
personal injury or loss of life. Installation and service must be
performed by a qualified installer, service agency or the gas
supplier.
50-2546
Version Française: www.enviro.com/fr.html

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the E33I and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Enviro E33I

Summary of Contents for Enviro E33I

  • Page 1 If the information in this manual is not followed exactly, a fire or explosion may result causing property damage, personal injury or loss of life. Installation and service must be performed by a qualified installer, service agency or the gas supplier. 50-2546 Version Française: www.enviro.com/fr.html...

  • Page 2: Safety Precautions

    Safety Precautions WARNING: FIRE OR EXPLOSION HAZARD Failure to follow safety warnings exactly could result in serious injury, death, or property damage. - Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance. - WHAT TO DO IF YOU SMELL GAS •...
  • Page 3 NEVER ALLOW CHILDREN shut. TO TOUCH GLASS. • If the E33I unit is pulled out of its installation, and the vent- A barrier designed to reduce the risk of burns from the air intake system is disconnected for any reason, ensure that...

  • Page 4: Table Of Contents

    Table of Contents Safety Precautions......................2 Table of Contents......................4 Codes And Approvals.......................5 Specifications........................6 Rating Label Location...................6 Dimensions......................6 E33I Options Dimensions..................7 Operating Instructions.....................8 Lighting and Turning Off Instructions..............8 Venturi Adjustment....................9 Normal Sounds During Operation.................9 Remote Control Operations...................9 Switching to Continuous Pilot Mode................10 Wall Mounting the Receiver.................12...

  • Page 5: Codes And Approvals

    After the unit has gone through the first burn, turn the unit off, let the unit get cold then remove the glass door and clean it with a good gas fireplace glass cleaner, available at your local ENVIRO dealer. See “D ”...

  • Page 6: Specifications

    The rating label is located on the left side of the unit, next to the receiver box. imensions 22.16 9.09 9.06 9.70 11.82 29.254 27.05 FRONT 21.55 19.78 16.64 18.55 18.06 18.03 LEFT RIGHT 20.20 Figure 1: E33I Exterior Dimensions.

  • Page 7: E33I Options Dimensions

    Specifications 8 " " 4 " 2 " Figure 2: E33I Contemporary Surround with Base Shelf and Riser. Table 1: E33I Options Dimensions. Regular Surround Contemporary Surround Extruded Surround Height 26.5” (673 mm) 26.5” (673 mm) 26.5” (673 mm) Width ”...

  • Page 8: Operating Instructions

    Operating Instructions For Your Safety, Read Safety Precautions And Lighting Instructions Before Operating WARNING: IF YOU DO NOT FOLLOW THESE INSTRUCTIONS EXACTLY A FIRE OR EXPLOSION MAY RESULT, CAUSING PROPERTY DAMAGE, PERSONAL INJURY OR LOSS OF LIFE. ighting anD uRning nstRuctions FOR YOUR SAFETY READ BEFORE OPERATING WARNING:...
  • Page 9 The Proflame GTMF is a modular remote control system that directs the functions of the E33I. The Proflame GTMF is configured to control the on/off main burner operation, its flame levels and provides on/ off and Smart thermostatic control of the appliance. The system controls a remotely actuated 120V/60Hz...

  • Page 10: Switching To Continuous Pilot Mode

    Operating Instructions Operating Instructions ATTENTION! - TURN “OFF” THE MAIN GAS SUPPLY OF THE APPLIANCE DURING INSTALLATION OR MAINTENANCE OF THE RECEIVER. - PLACE THE RECEIVER’S 3 POSITION SLIDER SWITCH IN THE “OFF” POSITION DURING INSTALLATION OR MAINTENANCE. - TURN “OFF” MAIN GAS SUPPLY TO THE APPLIANCE PRIOR TO REMOVING OR REINSERTING THE BATTERIES IN THE RECEIVER.
  • Page 11 Operating Instructions TRANSMITTER (Remote Control with LCD Display) The Proflame Transmitter uses a streamline design with a simple button layout and informative LCD display (Figure 5). The Transmitter is powered by three (3) AAA type batteries. A Mode Key is provided to Index between the features and a Thermostat Key is used to turn on/off or index through Thermostat functions (Figure 5 &...

  • Page 12: Wall Mounting The Receiver

    Operating Instructions emote ounting eceiVeR ptionaL The receiver can be removed from the unit and placed inside a standard Junction type wall box or another convenient location. This installation can take place up to 6’ft (1.8 m) from the appliance control valve. 1.
  • Page 13 Operating Instructions Turn off the Appliance Room Temperature Press the ON/OFF Key on the Transmitter. The Transmitter LCD display will only show the room temperature and Icon (see Figure 11). A single “beep” from the Receiver confirms reception of the command and both the pilot light (if the unit is not set to continuous pilot) and main burner will turn off.
  • Page 14 Operating Instructions Key lock This function will lock the keys to avoid unsupervised operation. To activate this function, press the MODE and UP keys at the same time and the a lock will appear (see Figure 15). To de-activate this function, press the MODE and UP Keys at the same time.

  • Page 15: Maintenance And Service

    The glass must be purchased from an ENVIRO dealer. No substitute materials are allowed. Remove the door (see page 15). The replacement glass will come with a new gasket installed. Remove any silicone remnants from the door.

  • Page 16: Glass Door Removal

    Maintenance And Service Lass emoVaL Figure 18: Door Release. Figure 19: Door Removal. Remove the glass door by placing the hooked end of the door release tool in the hole on the door latch mechanism (see Figure 18) and pulling the latch out then up. When the two (2) latches have been released, tilt the bottom of the door forward and then lift up to unhook the top door tabs (see Figure 19).

  • Page 17: Removing Valve Cover

    Maintenance And Service emoVing aLVe oVeR The valve cover can be removed to access the gas valve. 1. Use a T-20 screwdriver to remove the eight screws that hold down the valve cover shown in Fig. 20. VALVE COVER Figure 20: Valve Cover.

  • Page 18: Fuel Conversion

    Fuel Conversion TO BE INSTALLED BY A QUALIFIED SERVICE AGENCY ONLY Please read and understand these instructions before installing. WARNING: This conversion kit shall be installed by a qualified service agency in accordance with the manufacturer’s instructions and all applicable codes and requirements of the authority having jurisdiction.
  • Page 19 Fuel Conversion 10. Reinstall the burner, brick panels, log set, embers, and glass door. Also refer to s econDary nstallatIon in your Owner’s Manual. When re-installing the burner, ensure that nstallIng et anD mbers the burner to pilot hood relationship is similar to what is shown in Figure 21. 11.

  • Page 20: Initial Installation

    The vent length for the E33I must be between 8ft (2.44 m) and 30ft (9.14 m). This model is vented with a 3” intake and a 3” exhaust aluminum or stainless steel approved flex vent leading into a vertical termination cap.

  • Page 21: Venting Fireplace Inserts

    Check for any tears in the liner at this point. IMPORTANT: The screws that hold the vent collar plate in its approved position must be installed. NOTE: If the E33I unit is pulled out of its installation, and the vent air intake system is disconnected for any reason, ensure that the vent-air intake pipes are re-sealed with high-temperature sealant and reconnected with three (3) sheet metal screws evenly spaced.
  • Page 22 Make sure that all chimney cleanouts are tight fitting and will not permit air to leak into the chimney. Refractory, glass doors, screen rails, screen mesh and log grates can be removed from the fireplace before installing the E33. Figure 25: Installation of E33I DV .
  • Page 23 1. Plan your installation and clearances to combustibles. The E33I may be installed and vented into any solid fuel fireplace that has been installed in accordance with the National, Provincial/State and local building codes and has been constructed of non-combustible materials. Also refer to the I...

  • Page 24: Installing The Unit

    4. Check that the chimney clean outs fit properly. The flue damper must be fully blocked open or removed for installation of the E33I; the smoke shelves, shields and baffles may be removed if attached by mechanical fasteners.

  • Page 25: Zero Clearance Fireplace Installation

    Initial Installation QUALIFIED INSTALLERS ONLY (zc) f LeaRance iRepLace nstaLLation The metal floor of the ZC solid fuel firebox can be removed to allow the installation of the insert. THE CLEARANCE TO COMBUSTIBLE MATERIAL UNDER THE INSERT IS 4” (102 mm). YOU MUST USE THE LEVELING LEGS TO RAISE THE INSERT A MINIMUM OF 4”...
  • Page 26 Initial Installation QUALIFIED INSTALLERS ONLY Figure 30: Wiring Schematic.

  • Page 27: Gas Line Connection

    ½ psi (3.5 kPa). Figure 32: Gas Valve with Cover Removed. Table 5: Orifice and Pressure Information. E33I With Log Set & Proflame Valve Main Burner Natural Gas Propane Gas Orifice:...
  • Page 28 Initial Installation QUALIFIED INSTALLERS ONLY TO TEST VALVE PRESSURES (INPUT RATES): The pressure taps are located on the front side of the valve (see Figure 33). 1. Using a long flat bladed screwdriver, turn set screw counter-clockwise to loosen. 2. Place in (8 mm) I.D.

  • Page 29: Adjusting The Pilot Flame

    Initial Installation QUALIFIED INSTALLERS ONLY Djusting iLot Lame The pilot flow adjustment is set to maximum at the factory and should not need to be adjusted. The pilot flame should envelope ⅜” to ½” (10 to 13mm) of the Flame sensor (see Figure 34). However, should the need arise, follow Steps 1- 2 below.

  • Page 30: Secondary Installation

    The E33I Base Shelf (1⅝” (41 mm) high) and Base Shelf Riser (2⅛” (54 mm) high) are components that can be combined to create a riser with an overall height of 2 ” (55 mm). This shelf can be installed with or without the riser and can be used when the hearth in front of the unit is lower than the fireplace opening.
  • Page 31 Secondary Installation ptionaL RimmabLe aneLs Trimmable Panel Install: The trimmable panel is installed by sliding slots in the panel into screws on the stove. Two screws must be installed at the bottom of the Side Extensions. instaLLation: 1. Using a T20 screwdriver, screw one (1) #8-32 x .5”...
  • Page 32 Secondary Installation ptionaL RimmabLe aneLs Modifying the Surround Panel: The E33 Trimmable Surround Panels are large rectangular panels that may be cut for use in cases that a non- standard fireplace opening (e.g. an arched opening) is to be filled. Optionally this surround can be left uncut and placed in front of the fireplace opening.

  • Page 33: Surround Panel Installation

    Secondary Installation uRRounD aneL nstaLLation WARNING: The surround becomes hot when the unit is operating; ensure that the unit is turned off, and that it has cooled to room temperature before beginning this installation. Height Width 3-Sided Surround ” (673 mm) 44 ”...

  • Page 34: Safety Screen Installation

    Secondary Installation afety cReen nstaLLation The safety screen supplied with the unit must be Right Bracket Safety Screen Frame assembled first before it can be installed. When installed, the screen should not extrude out any farther than the surround panel if the cabinet extensions are still installed.
  • Page 35 Secondary Installation iRebox ineR anD uRneR emoVaL NOTE: The firebox liners are fragile and should be handled gently. 1. Ensure the E30 is turned off and allow the unit to cool. 2. Remove the glass door as shown in the m aIntenance anD erVIce lass...
  • Page 36 Secondary Installation et anD mbeR nstaLLation NOTE: The logs are fragile and should be handled gently. WARNING: Failure to position the parts in accordance with these diagrams or failure to use only parts specifically approved with this appliance may result in property damage or personal injury (see Figures 50 through 53).
  • Page 37 Secondary Installation et anD mbeR nstaLLation PLACEMENT OF EMBER BED Figure 52: Place the ember bed in the center of the burner tube and pull it forward as far as it will go. Ensure it DOES NOT obstruct any part of the burner. Left Side of Ember Bed Sitting inside burner tube The Ember Bed should sit flat on the support brackets as shown above.
  • Page 38 Secondary Installation Figure 53: Place the log grate in front of the burner tube using the two slotted mounts underneath. Figure 53: Third Stage Log Set Installation. Figure 54: The ember wool comes in chunks that can be ripped into smaller pieces.
  • Page 39 Secondary Installation Figure 56: Place the small left and right logs as shown. The bottoms of both pieces have contours to fit on the log grate. Figure 56: Sixth Stage Log Set Installation. Figure 57: Place the two center logs as shown.

  • Page 40: Troubleshooting

    TroubleShooting iagnostic Lash oDes 1. Fail to ignite: If there is no positive ignition, the board will go into lock out and the LED will blink 3 times in intervals until the system is reset. 2. Low battery condition (<4V): the LED indicator will blink one (1) time in intervals. 3.

  • Page 41: Troubleshooting

    TroubleShooting Problem Possible Cause Solution The pilot flame has gone out Thermostat · Turn it ON does not The On/Off switch is turn to OFF work The thermostat is set too high · Set the thermostat to a lower temperature ·...
  • Page 42 TroubleShooting Problem Possible Cause Solution · Turn the system off by pressing the ON/OFF button on the transmitter · After approximately 2 seconds press the ON/OFF button on the transmitter again. · In the manual flame control mode, use the down arrow button to reduce the flame to off, indicated by the word OFF displayed on the transmitter LCD screen.

  • Page 43: Parts List

    Dual Bulb Door Gasket (10ft) 50-634 Glass C/W Gasket (21.75” x 13.575”) 50-2523 Door Complete 50-2522 E33I Owner’s Manual 50-2546 E33I Conversion Kit NG to LP 50-2488 E33I Conversion Kit LP to NG 50-2538 Ceramic Wool Embers Only 50-893 Blank Filler Switch EG30-010...
  • Page 44 Parts List Reference Option Description Part Number Number Regular Surround Panel - E33I 50-2428 Contemporary Surround Panel - E33I 50-2429 Extruded Surround Panel - E33I 50-2430 Trimmable Surround Panel - E33I 50-2432 Base Shelf - E33I 50-2434 Base Shelf Riser - E33I...

  • Page 45: Parts Diagram - Components

    Parts Diagram - Components...

  • Page 46: Parts Diagram - Options

    Parts Diagram - Options...

  • Page 47: Warranty

    Exclusions conditions herein set forth, this product against defects in material and workmanship An expanded list of exclusions is available at www.enviro.com/help/warranty.html during the specified warranty period starting from the date of original purchase at retail. This warranty does not cover: In the event of a defect of material or workmanship during the specified warranty period, ƒ...

  • Page 48: Installation Data Sheet

    � NATURAL GAS (NAT) PROPANE(LPG) _________________________________________ INLET GAS PRESSURE:_________in WC PHONE:___________________________________ MAIN BURNER ORIFICE:__________# DMS PILOT ORIFICE #_________OR________in diam. INSTALLER’S SIGNATURE: _________________________________________ MANUFACTURED BY: SHERWOOD INDUSTRIES LTD. 6782 OLDFIELD RD. SAANICHTON, BC, CANADA V8M 2A3 www.enviro.com December 11, 2014 C-14472...
