E30GI
GAS INSERT - Glass Burner & Proflame IPI Valve
OWNER'S MANUAL
WARNING:
If the information in this manual is not followed exactly,
a fire or explosion may result causing property damage, personal
injury or loss of life. Installation and service must be performed by a
qualified installer, service agency or the gas supplier.
Report # 268-S-23-5
50-2581
Version Française: www.enviro.com/fr.html

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the E30GI and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Enviro E30GI

Summary of Contents for Enviro E30GI

  • Page 1 If the information in this manual is not followed exactly, a fire or explosion may result causing property damage, personal injury or loss of life. Installation and service must be performed by a qualified installer, service agency or the gas supplier. Report # 268-S-23-5 50-2581 Version Française: www.enviro.com/fr.html...

  • Page 2: Safety Precautions

    Safety Precautions WARNING: FIRE OR EXPLOSION HAZARD Failure to follow safety warnings exactly could result in serious injury, death, or property damage. - Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance. - WHAT TO DO IF YOU SMELL GAS •...
  • Page 3 A physical barrier is recommended if there • If the E30GI unit is pulled out of its installation, and are at risk individuals in the house. To restrict access to a the vent-air intake system is disconnected for any reason,...

  • Page 4: Table Of Contents

    Table of Contents Safety Precautions......................2 Table of Contents......................4 Codes And Approvals.......................5 Specifications........................6 Rating Label Location...................6 Dimensions......................6 E30I Options Dimensions..................7 Operating Instructions.....................8 Lighting and Turning Off Instructions..............8 Venturi Adjustment....................9 Normal Sounds During Operation.................9 Remote Control Operations...................9 Switching to Continuous Pilot Mode................10 Wall Mounting the Receiver.................12 Initializing the System for the First Time..............12 Maintenance And Service....................15...

  • Page 5: Codes And Approvals

    After the unit has gone through the first burn, turn the unit off, let the unit get cold then remove the glass door and clean it with a good gas fireplace glass cleaner, available at your local ENVIRO dealer. See “D ”...

  • Page 6: Specifications

    Specifications ating abeL ocation The rating label is located on the bottom of the unit, behind the front access door. imensions 17.89 6.94 6.94 15.61 13.76 27.50 2.07 26.59 24.38 21.07 14.06 16.27 FRONT 19.60 18.62 16.49 2.36 1.30 3.07 LEFT RIGHT 15.67...

  • Page 7: E30I Options Dimensions

    Specifications 8 " 25" 8 " 8 " Figure 2: E30GI Contemporary Surround with Base Shelf and Riser. Table 1: E30GI Options Dimensions. Regular Surround Contemporary Surround Extruded Surround Height 25” (635mm) 25” (635mm) 25” (635mm) Width ” (1013 mm) ”...

  • Page 8: Operating Instructions

    Operating Instructions For Your Safety, Read Safety Precautions And Lighting Instructions Before Operating WARNING: IF YOU DO NOT FOLLOW THESE INSTRUCTIONS EXACTLY A FIRE OR EXPLOSION MAY RESULT, CAUSING PROPERTY DAMAGE, PERSONAL INJURY OR LOSS OF LIFE. ighting anD uRning nstRuctions FOR YOUR SAFETY READ BEFORE OPERATING WARNING:...

  • Page 9: Venturi Adjustment

    The Proflame GTM is a modular remote control system that directs the functions of the E30GI. The Proflame GTM is configured to control the on/off main burner operation, its flame levels and provides on/ off and Smart thermostatic control of the appliance.

  • Page 10: Switching To Continuous Pilot Mode

    Operating Instructions Operating Instructions ATTENTION! - TURN “OFF” THE MAIN GAS SUPPLY OF THE APPLIANCE DURING INSTALLATION OR MAINTENANCE OF THE RECEIVER. - PLACE THE RECEIVER’S 3 POSITION SLIDER SWITCH IN THE “OFF” POSITION DURING INSTALLATION OR MAINTENANCE. - TURN “OFF” MAIN GAS SUPPLY TO THE APPLIANCE PRIOR TO REMOVING OR REINSERTING THE BATTERIES IN THE RECEIVER.
  • Page 11 Operating Instructions TRANSMITTER (Remote Control with LCD Display) The Proflame Transmitter uses a streamline design with a simple button layout and informative LCD display (Figure 5). The Transmitter is powered by three (3) AAA type batteries. A Mode Key is provided to Index between the features and a Thermostat Key is used to turn on/off or index through Thermostat functions (Figure 5 &...

  • Page 12: Wall Mounting The Receiver

    Operating Instructions emote ounting eceiVeR ptionaL The receiver can be removed from the unit and placed inside a standard Junction type wall box or another convenient location. This installation can take place up to 6’ft (1.8 m) from the appliance control valve. 1.
  • Page 13 Operating Instructions Turn off the Appliance Room Temperature Press the ON/OFF Key on the Transmitter. The Transmitter LCD display will only show the room temperature and Icon (see Figure 11). A single “beep” from the Receiver confirms reception of the command and both the pilot light (if the unit is not set to continuous pilot) and main burner will turn off.
  • Page 14 Operating Instructions Key lock This function will lock the keys to avoid unsupervised operation. To activate this function, press the MODE and UP keys at the same time and the a lock will appear (see Figure 15). To de-activate this function, press the MODE and UP Keys at the same time.

  • Page 15: Maintenance And Service

    The glass must be purchased from an ENVIRO dealer. No substitute materials are allowed. Remove the door (see page 15). The replacement glass will come with a new gasket installed. Remove any silicone remnants from the door.

  • Page 16: Glass Door Removal

    Maintenance And Service Lass emoVaL Figure 18: Door Release. Figure 19: Door Removal. Remove the glass door by placing the hooked end of the door release tool in the hole on the door latch mechanism (see Figure 18) and pulling the latch out then up. When the two (2) latches have been released, tilt the bottom of the door forward and then lift up to unhook the top door tabs (see Figure 19).

  • Page 17: Removing Valve Cover

    Maintenance And Service emoVing aLVe oVeR The valve cover can be removed to access the gas valve. 1. Remove the glass door as shown in m aIntenance anD erVIce lass emoVal 2. Remove the liners and burner. Refer to s econDary nstallatIon Irebox...

  • Page 18: Fuel Conversion

    Fuel Conversion TO BE INSTALLED BY A QUALIFIED SERVICE AGENCY ONLY Please read and understand these instructions before installing. WARNING: This conversion kit shall be installed by a qualified service agency in accordance with the manufacturer’s instructions and all applicable codes and requirements of the authority having jurisdiction.
  • Page 19 Fuel Conversion 10. Reinstall the burner, firebox liners, glass material, and glass door. Also refer to s econDary nstallatIon in your Owner’s Manual. When re-installing the burner, ensure that the burner to pilot hood relationship is similar to what is shown in Figure 21. 11.

  • Page 20: Initial Installation

    The vent length for the E30GI must be between 8ft (2.44 m) and 30ft (9.14 m). This model is vented with a 3” intake and a 3” exhaust aluminum or stainless steel flex vent leading into a vertical termination cap.

  • Page 21: Venting Fireplace Inserts

    Check for any tears in the liner at this point. IMPORTANT: The screws that hold the vent collar plate in its approved position must be installed. NOTE: If the E30GI unit is pulled out of its installation, and the vent air intake system is disconnected for any reason, ensure that the vent-air intake pipes are re-sealed with high-temperature sealant and reconnected with three (3) sheet metal screws evenly spaced.
  • Page 22 (either silicone or stove cement). The flue damper can be fully blocked open or removed for installation of the E30GI; the smoke shelves, shields and baffles may be removed if attached by mechanical fasteners. The fireplace and fireplace chimney must be clean, in good working order and constructed of non-combustible materials.

  • Page 23: Direct Vent Vertical Vent Termination

    1. Plan your installation and clearances to combustibles. The E30GI may be installed and vented into any solid fuel fireplace that has been installed in accordance with the National, Provincial/State and local building codes and has been constructed of non-combustible materials. Also refer to the I...

  • Page 24: Installing The Unit

    4. Check that the chimney clean outs fit properly. The flue damper must be fully blocked open or removed for installation of the E30GI; the smoke shelves, shields and baffles may be removed if attached by mechanical fasteners.

  • Page 25: Zero Clearance Fireplace Installation

    Initial Installation QUALIFIED INSTALLERS ONLY (zc) f LeaRance iRepLace nstaLLation The metal floor of the ZC solid fuel firebox can be removed to allow the installation of the insert. THE CLEARANCE TO COMBUSTIBLE MATERIAL UNDER THE INSERT IS 2 ” (57.2 mm). YOU MUST USE THE LEVELING LEGS TO RAISE THE INSERT A MINIMUM OF 2 ”...
  • Page 26 Initial Installation QUALIFIED INSTALLERS ONLY Figure 30: Wiring Schematic.

  • Page 27: Gas Line Connection

    ½ psi (3.5 kPa). Figure 32: Gas Valve with Cover Removed. Table 5: Orifice and Pressure Information. E30GI With Glass Burner & Proflame Valve Main Burner Natural Gas Propane Gas Orifice:...
  • Page 28 Initial Installation QUALIFIED INSTALLERS ONLY TO TEST VALVE PRESSURES (INPUT RATES): The pressure taps are located on the front side of the valve (see Figure 33). 1. Using a long flat bladed screwdriver, turn set screw counter-clockwise to loosen. 2. Place in (8 mm) I.D.

  • Page 29: Adjusting The Pilot Flame

    Initial Installation QUALIFIED INSTALLERS ONLY Djusting iLot Lame The pilot flow adjustment is set to maximum at the factory and should not need to be adjusted. The pilot flame should envelope ⅜” to ½” (10 to 13mm) of the flame sensor (see Figure 34). However, should the need arise, follow Steps 1- 2 below.

  • Page 30: Secondary Installation

    Additional Base Shelf Risers can be fastened together to increase the height in increments of 2⅛” (54 mm). This Base Shelf may be used in conjunction with the any of the E30GI surround panel options, and it may also be used with the E30GI Trimmable Surround. The Base Shelf and Riser are sold separately.

  • Page 31: Extension Bracket Removal

    Secondary Installation eDuceD epth The extension brackets installed on the outside of the stove are used to make the front of the surround panel flush with the safety screen. If the regular depth is required, skip to page 34. If the reduced install depth is required, the top and side extensions will need to be removed and the hardware re-located as outlined in steps 1-5 below: Top Cabinet...
  • Page 32 Secondary Installation maLLeR epth 1. Remove the four (4) screws from the outside of the Right Side Extension (see Figure 39). 2. Repeat for Left Side Extension. 3. Install three (3) screws halfway into the Cabinet as shown in Figure 41. Figure 39: Removing Extension Screws.

  • Page 33: Reduced Depth Optional 3 And 4 Sided Trimmable Panels

    Secondary Installation ptionaL iDeD RimmabLe aneLs Modifying the Surround Panel: The E30 Trimmable Surround Panels are large rectangular panels that may be cut for use in cases that a non- standard fireplace opening (e.g. an arched opening) is to be filled. Optionally this surround can be left uncut and placed in front of the fireplace opening.

  • Page 34: Regular Depth Optional 3 And 4 Sided Trimmable Panels

    Secondary Installation ptionaL iDeD RimmabLe aneLs Modifying the Surround Panel: The E30 Trimmable Surround Panels are large rectangular panels that may be cut for use in cases that a non- standard fireplace opening (e.g. an arched opening) is to be filled. Optionally this surround can be left uncut and placed in front of the fireplace opening.

  • Page 35: Surround Panel Installation

    Secondary Installation uRRounD aneL nstaLLation WARNING: The surround becomes hot when the unit is operating; ensure that the unit is turned off, and that it has cooled to room temperature before beginning this installation. Height Width 3-Sided Surround 25” (635 mm) ”...

  • Page 36: Safety Screen Installation

    Secondary Installation afety cReen nstaLLation The safety screen supplied with the unit must be Right Bracket Safety Screen Frame assembled first before it can be installed. When installed, the screen should not extrude out any farther than the surround panel if the cabinet extensions are still installed.

  • Page 37: Firebox Liner And Burner Tray Removal / Installation

    WARNING: Failure to position the parts in accordance with these diagrams or failure to use only parts specifically approved with this appliance may result in property damage or personal injury. 1. Ensure the E30GI is turned off and allow the unit to cool. 2. Remove the glass door as shown in the m...

  • Page 38: Installing The Glass Beads

    Secondary Installation nstaLLing the Lass eaDs Pour the glass beads into the tray and evenly distribute over the entire tray. Ensure that the pilot box remains clear of any glass. Burner tray with glass installed. Figure 60:...

  • Page 39: Troubleshooting

    TroubleShooting iagnostic Lash oDes 1. Fail to ignite: If there is no positive ignition, the board will go into lock out and the LED will blink 3 times in intervals until the system is reset. 2. Low battery condition (<4V): the LED indicator will blink one (1) time in intervals. 3.
  • Page 40 TroubleShooting Problem Possible Cause Solution The pilot flame has gone out Thermostat · Turn it ON does not The On/Off switch is turn to OFF work The thermostat is set too high · Set the thermostat to a lower temperature ·...
  • Page 41 TroubleShooting Problem Possible Cause Solution · Turn the system off by pressing the ON/OFF button on the transmitter · After approximately 2 seconds press the ON/OFF button on the transmitter again. · In the manual flame control mode, use the down arrow button to reduce the flame to off, indicated by the word OFF displayed on the transmitter LCD screen.

  • Page 42: Parts List

    50-2781 PSE IPI Pilot Assembly 50-3026 Remote Receiver 50-2007 E30GI Owners Manual 50-2581 E30GI Conversion Kit NG to LP 50-2487 E30GI Conversion Kit LP to NG 50-2542 Porcelain Liner Set 50-2427 12 oz. Can of Metallic Black Touch Up Paint...
  • Page 43 Parts List Reference Option Description Part Number Number Regular Surround Panel 50-2418 Contemporary Surround Panel 50-2419 Extruded Surround Panel 50-2420 Trim-able Surround Panel 50-2422 Base Shelf 50-2424 Base Shelf Riser 50-2425 Four Sided Surround 50-2484 Four Sided Trimmable Panel 50-2485 Safety Screen 50-2495 Oversized Contemporary Surround Panel...

  • Page 44: Parts Diagram - Components

    Parts Diagram - Components...

  • Page 45: Parts Diagram - Options

    Parts Diagram - Options...
  • Page 46 NOTES...

  • Page 47: Warranty

    Exclusions conditions herein set forth, this product against defects in material and workmanship An expanded list of exclusions is available at www.enviro.com/help/warranty.html during the specified warranty period starting from the date of original purchase at retail. This warranty does not cover: In the event of a defect of material or workmanship during the specified warranty period, ƒ...

  • Page 48: Installation Data Sheet

    � NATURAL GAS (NAT) PROPANE(LPG) _________________________________________ INLET GAS PRESSURE:_________in WC PHONE:___________________________________ MAIN BURNER ORIFICE:__________# DMS PILOT ORIFICE #_________OR________in diam. INSTALLER’S SIGNATURE: _________________________________________ MANUFACTURED BY: SHERWOOD INDUSTRIES LTD. 6782 OLDFIELD RD. SAANICHTON, BC, CANADA V8M 2A3 www.enviro.com December 11, 2014 C-14469...
