SHERWOOD INDUSTRIES IS AN ENVIRONMENTALLY RESPONSIBLE COMPANY. THIS MANUAL IS PRINTED ON RECYCLED PAPER.
PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE
OWNER'S MANUAL
WHAT TO DO IF YOU SMELL GAS
• Open windows/extinguish any open flame.
• Do not try to light any appliance.
• Do not touch any electrical switch or use any
phone in your building.
• Immediately call your gas supplier from a
neighbour's phone. Follow the gas supplier's
instructions.
• If you cannot reach your gas supplier, call the fire
department.
If the information in this manual is not followed exactly, a fire or explosion
may result causing property damage, personal injury or loss of life.
Installation and service must be performed by a qualified installer, service
Do not store or use gasoline or other flammable vapours and liquids in the
Massachusetts installations (Warning): This product must be installed by a licensed
plumber or gas fitter when installed within the Commonwealth of Massachusetts. Other
Massachusetts code requirements: Flexible connector must not be longer than 36in, shut
off valve must be a "T" handle gas cock; only direct vent sealed combustion products are
approved for bedrooms/bathrooms; fireplace dampers must be removed or welded in the
open position prior to the installation of a fireplace insert or gas log.
WARNING
agency or the gas supplier.
FOR YOUR SAFETY
vicinity of this or any other appliance.
FOCUS
B Y : S H E R W O O D I N D U S T R I E S L T D
This appliance is
only for use with
the type of gas
indicated on the
rating plate. This
appliance is not
convertible for use
with other gases,
unless a certified
kit is used.
EG31-118

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Enviro and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Enviro Enviro

  • Page 1 SHERWOOD INDUSTRIES IS AN ENVIRONMENTALLY RESPONSIBLE COMPANY. THIS MANUAL IS PRINTED ON RECYCLED PAPER. PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE FOCUS B Y : S H E R W O O D I N D U S T R I E S L T D OWNER’S MANUAL...
  • Page 2: Safety Precautions

    Safety Precautions FOR SAFE INSTALLATION AND OPERATION OF YOUR “ENVIRO” HEATER, PLEASE CAREFULLY READ THE FOLLOWING INFORMATION: • All ENVIRO gas-fired appliances must be installed • To prevent injury, do not allow anyone who is in accordance with their instructions. Carefully read all unfamiliar with the stove to operate it.
  • Page 3: Table Of Contents

    Table of Contents Safety Precautions....................2 Table of Contents.....................3 Codes And Approvals....................4 Specifications......................5 Dimensions....................5 Clearances to Combustibles................5 Rating Label Location..................5 Initial Installation....................6 B Vent Model....................6 Automatic Flue Gas Spill Switch..............6 Direct Vent Model..................6 Venting Fireplace Inserts................7 Direct Vent Restrictor Ring................8 Adjusting Venturi Air Settings................8 Preparing Your Focus For Installation............8 Converting A Direct Vent Fireplace To A B-Vented Fireplace......10 Converting A B-Vent Fireplace To A Direct Vented Fireplace......10...
  • Page 4: Codes And Approvals

    CAN/CGA 2.17-M91 GAS FIRED APPLIANCES FOR HIGH ALTITUDES CSA P.4.1-02 TESTING METHOD FOR MEASURING ANNUAL FIREPLACE EFFICIENCY This ENVIRO FOCUS Fireplace: • Has been certified for use with either natural or propane gases. (See rating label.) • Is not for use with solid fuels.
  • Page 5: Specifications

    Specifications WARNING: Operation of this heater when not connected to a properly installed and maintained venting system can result in carbon monoxide (CO) poisoning and possible death. IMENSIONS �� � � � ��� ��� �� ��� ����� ��� �� � �...
  • Page 6: Initial Installation

    Initial Installation WARNING: Operation of this heater when not connected to a properly installed and maintained venting system can result in carbon monoxide (CO) poisoning and possible death. ODEL WARNING: This appliance has been designed to operate by drawing combustion air and dilution air from the room.
  • Page 7: Venting Fireplace Inserts

    ENTING IREPLACE NSERTS The ENVIRO FOCUS may be installed and vented into any solid fuel fireplace that has been installed in accordance with the National, Provincial/State and local building codes and has been constructed of non-combustible materials. An approved chimney liner and rain cap must be used. A throat connector or flashing must be installed to ensure a tight seal, top performance, safety and efficiency.
  • Page 8: Direct Vent Restrictor Ring

    Initial Installation QUALIFIED INSTALLERS ONLY IRECT ESTRICTOR DIRECT VENT ONLY: The maximum vertical vent height for a direct vent installation is 25 feet (7.62 m). Use the vent Vent Restrictor Ring restrictor ring for installations above 15 feet (4.57 m). See Figure 4 for installation of restrictor ring.
  • Page 9 Initial Installation 4. Remove the vent collar plate from the top of the stove by unscrewing the two (2) T-20 Torx screws located on the center top of the stove. Slide collar plate backwards. Properly secure the vent collar plate to the flexible vent pipe liner(s) previously installed in the chimney.
  • Page 10: Converting A Direct Vent Fireplace To A B-Vented Fireplace

    Initial Installation QUALIFIED INSTALLERS ONLY A B-V ONVERTING IRECT IREPLACE ENTED IREPLACE Parts required for conversion; 1 - 300°F (149°C) manual reset spill switch and wires 1 - Drafthood (4’’ chimney connection) 2 - Air channels 300°F (140°F) 1 - Drafthood diverter Spill Switch 1.
  • Page 11: Electrical Requirements

    Initial Installation QUALIFIED INSTALLERS ONLY LECTRICAL EQUIREMENTS The Focus will operate without electrical power. This model has a Millivolt gas control which uses the pilot flame to generate enough electricity to operate the main burners. This appliance when equipped with a blower, must be electrically connected and grounded in accordance with local codes or in the absence of local codes, with the current CSA C22.1 CANADIAN ELECTRICAL CODE...
  • Page 12: Installing Fan Controller

    Initial Installation QUALIFIED INSTALLERS ONLY NSTALLING ONTROLLER When using the cast iron faceplate, bay door assembly, or custom surround panel the fan controller, normally mounted in the surround panel, must be relocated to control panel. To accomplish this, cut one wire tie so that the wires can be properly routed.
  • Page 13: Fuel Conversion

    Initial Installation QUALIFIED INSTALLERS ONLY ONVERSION Warning: A qualified service technician, in accordance with the manufacturer’s instructions as well as all applicable authority having jurisdiction, shall install this conversion kit. If the information in these instructions is not followed exactly, a fire, explosion or CO poisoning, may result.
  • Page 14: Gas Line Connection

    Initial Installation QUALIFIED INSTALLERS ONLY ONNECTION Warning: Only persons licensed to work with gas piping may make the necessary gas connections to this appliance. Gas Line Connection: •This fireplace is equipped with a certified flexible pipe located on the right side of the unit, terminating in a 3⁄8” male NPT fitting.
  • Page 15: Secondary Installation

    Use of other foreign materials on the burners may create dangerous conditions. If over time, through cleaning and servicing, these embers require replacement , contact your nearest Enviro dealer. Figure 20: Focus Log Placement 3.
  • Page 16: Removing And Installing The Brick Panel

    Secondary Installation IMPORTANT: Upon the first light up after installing logs and embers, watch for ignition to ALL burner ports. If a long delay is noted wait for the appliance to cool down: •Open the front door of the appliance •Carefully reposition embers, making sure that the...
  • Page 17: Operating Instructions

    Operating Instructions FOR YOUR SAFETY READ COMPLETELY BEFORE OPERATING. WARNING: IF YOU DO NOT FOLLOW THESE INSTRUCTIONS EXACTLY, A FIRE OR EXPLOSION MAY RESULT CAUSING PROPERTY DAMAGE, PERSONAL INJURY OR LOSS OR LIFE. This appliance is equipped with a pilot that must be lit by hand by following these instructions exactly. A) BEFORE LIGHTING smell all around the appliance area for gas, and next to the floor because some gas is heavier than air and will settle on the floor.
  • Page 18: Maintenance And Service

    • Install the new piece of glass with the large bulb in the gasket tape against the unit. Place the joint in the tape in a bottom corner. Close door. Glass must be purchased from an Enviro dealer. No substitute materials are allowed. Warning: Clearances must be sufficient to allow access for maintenance and service Warning: Failure to position the parts in accordance with this manual, or failure to use only parts specifically approved with this appliance may result in property damage or personal injury.
  • Page 19: Trouble Shooting

    Trouble Shooting Problem Possible Cause Solution Spark will not arc to the Defective piezo ignitor • Check connections to ignitor pilot after repeatedly • If ignitor connections are good but no spark, replace pressing the spark ignitor ignitor. Broken spark electrode •...
  • Page 20 Parts List - Components Reference Number Part Description Part Number Extension Knob (Pilot) 30-030 Extension Knob (HI-LO) 30-031 Relief Door & Gasket 30-034 Blank Orifice #73 50-343 BV Flue Collar Gasket 50-528 DV Flue Collar Gasket 50-529 Log Set & Embers 50-588 Ceramic Brick Liner 50-610...
  • Page 21: Parts List - Components

    Parts List - Components Reference Number Part Description Part Number Stainless Steel Flex Connector with 3⁄8” Elbow 18” Long EC-024 FPI Burner Switch EC-026 FPI Fan Controller - 115 V EC-039 FPI Fan Controller Knob EC-041 Domestic Power Cord - 115 V EC-042 Heyco Strain Relief EC-044...
  • Page 22: Parts Diagram - Body

    Parts Diagram - Body...
  • Page 23: Parts List - Surrounds & Fascia

    Parts List - Surrounds & Fascia Reference Number Part Description Part Number Steel Bay Face - Polished Nickel 50-092 Steel Bay Face With Glass - Painted 50-141 Steel Bay Cover - Gold 50-142 Steel Bay Cover - Polished Nickel 50-143 Steel Bay Cover - Painted 50-531 Steel Bay 3 Pieces Glass Set with Tape...
  • Page 24: Parts Diagram - Surrounds & Fascia

    Parts Diagram - Surrounds & Fascia...
  • Page 25: Parts List - Cast

    Parts List - Cast Reference Number Part Description Part Number Cast surround only - Painted 30-036 Cast surround only - Antique White 30-035AW Cast surround only - Diamond Black 30-035DB Cast surround only - Inferno Red 30-035IR Cast surround only - Pearl Grey 30-035PG Cast surround only - Wedgewood Blue 30-035WB...
  • Page 26 Parts List - Cast Reference Number Part Description Part Number Cast front only (no surround, glass, valve door, or clip) - Antique White 50-403 Cast front only (no surround, glass, valve door, or clip) - Diamond Black 50-404 Cast front only (no surround, glass, valve door, or clip) - Inferno Red 50-405 Cast front only (no surround, glass, valve door, or clip) - Pearl Grey 50-406...
  • Page 27: Parts Diagram- Cast Bay Front

    Parts Diagram- Cast Bay Front...
  • Page 28: Warranty

    The warranty does not cover removal and reinstallation costs. Sherwood Industries Ltd. reserves the right to repair or replace the defective product. The shipping costs are to be paid by the consumer. All warranties by the manufacturer are set forth and no claim shall be made against the manufacturer on any oral warranty or representation.
  • Page 29: Installation Data Sheet

    _________________________________________ NATURAL GAS (NAT) PROPANE(LPG) _________________________________________ INLET GAS PRESSURE:_________in wc PHONE:___________________________________ MAIN BURNER ORIFICE:__________# DMS PILOT ORIFICE #_________OR________in diam. INSTALLER’S SIGNATURE: _________________________________________ MANUFACTURED BY: SHERWOOD INDUSTRIES LTD. 6782 OLDFIELD RD. SAANICHTON, BC, CANADA V8M 2A3 www.envirofire.biz February 21, 2005 C-10472...

This manual is also suitable for:

Focus bvFocus dvFocus ngFocus lpg
