E30I
GAS INSERT - Log Set & Proflame IPI Valve
OWNER'S MANUAL
WARNING:
If the information in this manual is not followed exactly,
a fire or explosion may result causing property damage, personal
injury or loss of life. Installation and service must be performed by a
qualified installer, service agency or the gas supplier.
Report # 268-S-23-5
50-2597
Version Française: www.enviro.com/fr.html
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the E30I and is the answer not in the manual?

Questions and answers

Related Manuals for Enviro E30I

Summary of Contents for Enviro E30I

  • Page 1 If the information in this manual is not followed exactly, a fire or explosion may result causing property damage, personal injury or loss of life. Installation and service must be performed by a qualified installer, service agency or the gas supplier. Report # 268-S-23-5 50-2597 Version Française: www.enviro.com/fr.html...

  • Page 2: Safety Precautions

    Safety Precautions WARNING: FIRE OR EXPLOSION HAZARD Failure to follow safety warnings exactly could result in serious injury, death, or property damage. - Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance. - WHAT TO DO IF YOU SMELL GAS •...
  • Page 3 A physical barrier is recommended if there • If the E30I unit is pulled out of its installation, and are at risk individuals in the house. To restrict access to a the vent-air intake system is disconnected for any reason,...

  • Page 4: Table Of Contents

    Safety Precautions........................2 Table of Contents........................4 Codes And Approvals......................5 Specifications........................6 Rating Label Location....................6 Dimensions......................6 Install Depth......................7 E30I Options Dimensions....................8 Operating Instructions......................9 Lighting and Turning Off Instructions................9 Venturi Adjustment....................10 Normal Sounds During Operation................10 Remote Control Operations..................10 Switching to Continuous Pilot Mode................11 Battery Holder......................12 Initializing the System for the First Time..............13...

  • Page 5: Codes And Approvals

    After the unit has gone through the first burn, turn the unit off, let the unit get cold then remove the glass door and clean it with a good gas fireplace glass cleaner, available at your local ENVIRO dealer. See “D ”...

  • Page 6: Specifications

    3.07 LEFT RIGHT 17.71 Figure 1: E30I Exterior Dimensions. nstaLL epth If the available depth of install is less than 16”, the stove depth can be reduced to 14.125” by removing the cabinet extension brackets; however, doing so will cause the safety screen to protrude past the front of the surround panel.

  • Page 7: Install Depth

    Specifications nstaLL epth 16.000 Figure 1a: E30I Install Dimensions.

  • Page 8: E30I Options Dimensions

    Specifications 8 " 25" 8 " 8 " Figure 2: E30I Contemporary Surround with Base Shelf and Riser. Table 1: E30I Options Dimensions. Regular Surround Contemporary Surround Extruded Surround Height 25” (635mm) 25” (635mm) 25” (635mm) Width ” (1013 mm) ”...

  • Page 9: Operating Instructions

    Operating Instructions For Your Safety, Read Safety Precautions And Lighting Instructions Before Operating WARNING: IF YOU DO NOT FOLLOW THESE INSTRUCTIONS EXACTLY A FIRE OR EXPLOSION MAY RESULT, CAUSING PROPERTY DAMAGE, PERSONAL INJURY OR LOSS OF LIFE. ighting anD uRning nstRuctions FOR YOUR SAFETY READ BEFORE OPERATING WARNING:...

  • Page 10: Venturi Adjustment

    Operating Instructions entuRi Djustment The venturi adjustment lever is located on the right side of the unit, below the door (see Figure 4). To avoid touching hot surfaces under the unit, use the Door Tool to adjust the venturi. The venturi allows the amount of air coming into the fireplace to be adjusted in order to accommodate different climates and venting arrangements.
  • Page 11 Operating Instructions Operating Instructions ystem escRiption The Proflame 2 Remote Control System consists of two (2) elements: 1. Proflame 2 Transmitter. 2. Integrated Fireplace Controller (IFC) and a wiring harness to connect the Receiver to the gas valve, stepper motor and Fan Control Module. ATTENTION! - TURN “OFF”...

  • Page 12: Battery Holder

    Operating Instructions CPI Mode Figure 6: Proflame 2 Transmitter LCD Screen. atteRy oLDeR The Battery Holder (Figure 7) connects directly to the IFC with a wiring harness. The IFC is powered by four (4) AA type batteries. The IFC accepts commands via radio frequency from the Transmitter to operate the appliance in accordance with the particular Proflame system configuration.

  • Page 13: Switching To Continuous Pilot Mode

    Operating Instructions peRating RoceDuRe Initializing The System For The First Time Install the four (4) AA batteries into the IFC battery holder. Note the polarity of the battery and insert into the battery bay as indicated on the body of the battery holder. Press the reset button on the Battery Holder marked “PRG” (see Figure 7).
  • Page 14 Operating Instructions Turn off the Appliance Press the ON/OFF Key on the Transmitter. The Transmitter LCD display Room Temperature will only show the room temperature and Icon (see Figure 10). A single “beep” from the IFC confirms reception of the command and both the pilot light (if the unit is not set to continuous pilot) and main burner will turn off.

  • Page 15: Fan Control

    Operating Instructions Fan Control The E30LI comes with a convection fan that can be controlled with the Transmitter. The fan speed can be adjusted thorugh six (6) speeds. To control the fan press the MODE key (Figure 5) to index to the fan control icon (Figure 13).

  • Page 16: Maintenance And Service

    The glass must be purchased from an ENVIRO dealer. No substitute materials are allowed. Remove the door (see page 15). The replacement glass will come with a new gasket installed. Remove any silicone remnants from the door.

  • Page 17: Glass Door Removal

    Maintenance And Service Lass emoVaL Figure 18: Door Release. Figure 19: Door Removal. Remove the glass door by placing the hooked end of the door release tool in the hole on the door latch mechanism (see Figure 18) and pulling the latch out then up. When the two (2) latches have been released, tilt the bottom of the door forward and then lift up to unhook the top door tabs (see Figure 19).

  • Page 18: Removing Valve Cover

    Maintenance And Service emoVing aLVe oVeR The valve cover can be removed to access the gas valve. 1. Remove the glass door as shown in m aIntenance anD erVIce lass emoVal 2. Remove the liners and burner. Refer to s econDary nstallatIon Irebox...

  • Page 19: Fuel Conversion

    Fuel Conversion TO BE INSTALLED BY A QUALIFIED SERVICE AGENCY ONLY Please read and understand these instructions before installing. WARNING: This conversion kit shall be installed by a qualified service agency in accordance with the manufacturer’s instructions and all applicable codes and requirements of the authority having jurisdiction.
  • Page 20 Fuel Conversion 10. Reinstall the burner, brick panels, log set, embers, and glass door. Also refer to s econDary nstallatIon in your Owner’s Manual. When re-installing the burner, ensure that nstallIng et anD mbers the burner to pilot hood relationship is similar to what is shown in Figure 21. 11.

  • Page 21: Initial Installation

    The vent length for the E30I must be between 8ft (2.44 m) and 30ft (9.14 m). This model is vented with a 3” intake and a 3” exhaust aluminum or stainless steel flex vent leading into a vertical termination cap.

  • Page 22: Venting Fireplace Inserts

    Check for any tears in the liner at this point. IMPORTANT: The screws that hold the vent collar plate in its approved position must be installed. NOTE: If the E30I unit is pulled out of its installation, and the vent air intake system is disconnected for any reason, ensure that the vent-air intake pipes are re-sealed with high-temperature sealant and reconnected with three (3) sheet metal screws evenly spaced.
  • Page 23 (either silicone or stove cement). The flue damper can be fully blocked open or removed for installation of the E30I; the smoke shelves, shields and baffles may be removed if attached by mechanical fasteners. The fireplace and fireplace chimney must be clean, in good working order and constructed of non-combustible materials.

  • Page 24: Direct Vent Vertical Vent Termination

    1. Plan your installation and clearances to combustibles. The E30I may be installed and vented into any solid fuel fireplace that has been installed in accordance with the National, Provincial/State and local building codes and has been constructed of non-combustible materials. Also refer to the I...

  • Page 25: Installing The Unit

    4. Check that the chimney clean outs fit properly. The flue damper must be fully blocked open or removed for installation of the E30I; the smoke shelves, shields and baffles may be removed if attached by mechanical fasteners.

  • Page 26: Zero Clearance Fireplace Installation

    Initial Installation QUALIFIED INSTALLERS ONLY (zc) f LeaRance iRepLace nstaLLation The metal floor of the ZC solid fuel firebox can be removed to allow the installation of the insert. THE CLEARANCE TO COMBUSTIBLE MATERIAL UNDER THE INSERT IS 2 ” (57.2 mm). YOU MUST USE THE LEVELING LEGS TO RAISE THE INSERT A MINIMUM OF 2 ”...

  • Page 27: Wiring Schematic

    Initial Installation QUALIFIED INSTALLERS ONLY Figure 30: Wiring Schematic.

  • Page 28: Gas Line Connection

    ½ psi (3.5 kPa). Figure 32: Gas Valve with Cover Removed. Table 6: Orifice and Pressure Information. E30I With Log Set & Proflame Valve Main Burner Natural Gas Propane Gas Orifice:...
  • Page 29 Initial Installation QUALIFIED INSTALLERS ONLY TO TEST VALVE PRESSURES (INPUT RATES): The pressure taps are located on the front side of the valve (see Figure 33). 1. Using a long flat bladed screwdriver, turn set screw counter-clockwise to loosen. 2. Place in (8 mm) I.D.

  • Page 30: Adjusting The Pilot Flame

    Initial Installation QUALIFIED INSTALLERS ONLY Djusting iLot Lame The pilot flow adjustment is set to maximum at the factory and should not need to be adjusted. The pilot flame should envelope ⅜” to ½” (10 to 13mm) of the flame sensor (see Figure 34). However, should the need arise, follow Steps 1- 2 below.

  • Page 31: Secondary Installation

    The E30I Base Shelf (1⅝” (41 mm) high) and Base Shelf Riser (2⅛” (54 mm) high) are components that can be combined to create a riser with an overall height of 2 ” (55 mm). This shelf can be installed with or without the riser and can be used when the hearth in front of the unit is lower than the fireplace opening.

  • Page 32: Extension Bracket Removal

    Secondary Installation eDuceD epth The extension brackets installed on the outside of the stove are used to make the front of the surround panel flush with the safety screen. If the regular depth is required, skip to page 34. If the reduced install depth is required, the top and side extensions will need to be removed and the hardware re-located as outlined in steps 1-5 below: Top Cabinet...
  • Page 33 Secondary Installation maLLeR epth 1. Remove the four (4) screws from the outside of the Right Side Extension (see Figure 39). 2. Repeat for Left Side Extension. 3. Install three (3) screws halfway into the Cabinet as shown in Figure 41. Figure 39: Removing Extension Screws.

  • Page 34: Reduced Depth Optional 3 And 4 Sided Trimmable Panels

    Secondary Installation ptionaL iDeD RimmabLe aneLs Modifying the Surround Panel: The E30 Trimmable Surround Panels are large rectangular panels that may be cut for use in cases that a non- standard fireplace opening (e.g. an arched opening) is to be filled. Optionally this surround can be left uncut and placed in front of the fireplace opening.

  • Page 35: Regular Depth Optional 3 And 4 Sided Trimmable Panels

    Secondary Installation ptionaL iDeD RimmabLe aneLs Modifying the Surround Panel: The E30 Trimmable Surround Panels are large rectangular panels that may be cut for use in cases that a non- standard fireplace opening (e.g. an arched opening) is to be filled. Optionally this surround can be left uncut and placed in front of the fireplace opening.

  • Page 36: Surround Panel Installation

    Secondary Installation uRRounD aneL nstaLLation WARNING: The surround becomes hot when the unit is operating; ensure that the unit is turned off, and that it has cooled to room temperature before beginning this installation. Height Width 3-Sided Surround 25” (635 mm) ”...

  • Page 37: Safety Screen Installation

    Secondary Installation afety cReen nstaLLation The safety screen supplied with the unit must be Right Bracket Safety Screen Frame assembled first before it can be installed. When installed, the screen should not extrude out any farther than the surround panel if the cabinet extensions are still installed.

  • Page 38: Firebox Liner And Burner Tube Removal / Installation

    WARNING: Failure to position the parts in accordance with these diagrams or failure to use only parts specifically approved with this appliance may result in property damage or personal injury. 1. Ensure the E30I is turned off and allow the unit to cool. 2. Remove the glass door as shown in the m...

  • Page 39: Log Set And Ember Removal / Installation

    Secondary Installation et anD mbeR nstaLLation NOTE: The logs are fragile and should be handled gently. WARNING: Failure to position the parts in accordance with these diagrams or failure to use only parts specifically approved with this appliance may result in property damage or personal injury.
  • Page 40 Secondary Installation Figure 65: Place the log grate in front of the burner tube using the two slotted mounts underneath. Figure 66 & 67: Fill in the bottom of the firebox using the coal nuggets supplied with the unit as Figure 65: Third Stage Log Set Installation.
  • Page 41 Secondary Installation Figure 70: Place the small left and right logs as shown. The bottoms of both pieces have contours to fit on the log grate. Figure 70: Sixth Stage Log Set Installation. Figure 71: Place the two center logs as shown.

  • Page 42: Troubleshooting

    TroubleShooting iagnostic Lash oDes 1. Fail to ignite: If there is no positive ignition, the board will go into lock out and the LED will blink 3 times in intervals until the system is reset. 2. Low battery condition (<4V): the LED indicator will blink one (1) time in intervals. 3.
  • Page 43 TroubleShooting Problem Possible Cause Solution The pilot flame has gone out Thermostat · Turn it ON does not The On/Off switch is turn to OFF work The thermostat is set too high · Set the thermostat to a lower temperature ·...
  • Page 44 TroubleShooting Problem Possible Cause Solution · Turn the system off by pressing the ON/OFF button on the transmitter · After approximately 2 seconds press the ON/OFF button on the transmitter again. · In the manual flame control mode, use the down arrow button to reduce the flame to off, indicated by the word OFF displayed on the transmitter LCD screen.

  • Page 45: Parts List

    Proflame 2 Battery Holder (0.584.103) 50-3204 Proflame 2 IFC Wire Harness (0.584.922) 50-3203 E30I Owners Manual 50-2597 E30I Conversion Kit NG to LP 50-2486 E30I Conversion Kit LP to NG 50-2541 Ceramic Wool Embers Only 50-893 E30 Logset (9 Pcs.)
  • Page 46 Parts List Reference Option Description Part Number Number Regular Surround Panel 50-2418 Contemporary Surround Panel 50-2419 Extruded Surround Panel 50-2420 Trim-able Surround Panel 50-2422 Base Shelf 50-2424 Base Shelf Riser 50-2425 Four Sided Surround 50-2484 Four Sided Trimmable Panel 50-2485 E30 Borderview Surround Panel 50-3166 E30 Borderview Plus Surround Panel...

  • Page 47: Parts Diagram - Components

    Parts Diagram - Components...

  • Page 48: Parts Diagram - Options

    Parts Diagram - Options...
  • Page 49 Parts Diagram - Options...

  • Page 50: Notes

    NOTES...

  • Page 51: Warranty

    Exclusions conditions herein set forth, this product against defects in material and workmanship An expanded list of exclusions is available at www.enviro.com/help/warranty.html during the speci ed warranty period starting from the date of original purchase at retail. This warranty does not cover:...

  • Page 52: Installation Data Sheet

    � NATURAL GAS (NAT) PROPANE(LPG) _________________________________________ INLET GAS PRESSURE:_________in WC PHONE:___________________________________ MAIN BURNER ORIFICE:__________# DMS PILOT ORIFICE #_________OR________in diam. INSTALLER’S SIGNATURE: _________________________________________ MANUFACTURED BY: SHERWOOD INDUSTRIES LTD. 6782 OLDFIELD RD. SAANICHTON, BC, CANADA V8M 2A3 www.enviro.com February 10, 2016 C-14812...
