Component Descriptions and Connections
Table 19 • Pinout Definition (continued)
J21-Pin Net Name
61 AV1_1
63 AGND
65 AV1_3
67 AGND
69 NC
71 AGND
73 ADC2
75 AGND
77 ADC4
79 AGND
81 ADC6
83 AGND
85 NC
87 AGND
89 NC
91 AC1
93 AGND
95 DGND
97 3.3V
99 3.3V
1. Digital signal
2. Analog signal
Pin
Number Description
2
W9 ABPS2
AGND Analog ground
2
W12 ABPS6
AGND Analog ground
NC NC
AGND Analog ground
V9 ADC2
AGND Analog ground
U12 ADC4
AGND Analog ground
2
V11 ADC6
AGND Analog ground
NC NC
AGND Analog ground
NC NC
2
U9 CM1
AGND Analog ground
DGND Digital ground
Power Power
Power Power
UG0209 User Guide Revision 7.1
J21-Pin Net Name
62 AV2_1
64 AGND
66 AV2_3
68 AGND
70 NC
72 AGND
74 ADC3
76 AGND
78 ADC5
80 AGND
82 ADC7
84 AGND
86 NC
88 AGND
90 NC
92 AGND
94 AGND
96 DGND
98 3.3V
100 3.3V
Pin
Number Description
2
AB7 ABPS3
AGND Analog ground
2
Y11 ABPS7
AGND Analog ground
NC NC
AGND Analog ground
AB8 ADC3
AGND Analog ground
V12 ADC5
AGND Analog ground
2
T12 ADC7
AGND Analog ground
NC NC
AGND Analog ground
NC NC
AGND Analog ground
AGND Analog ground
DGND Digital ground
Power Power
Power Power
