Installation and Settings

3 Installation and Settings
This section provides information about software and hardware settings required to run the
pre-programmed demo design in the SmartFusion Evaluation Kit.
3.1

Software Settings

Download and install the latest release of Microsemi Libero
the Microsemi SoC Products Group website and register for your free Silver license. For instructions on
how to install Libero SoC and SoftConsole, refer to the Libero SoC Installation and Licensing Guide,
available at www.microsemi.com/soc/documents/libero_ug.pdf.
Refer to the Installing IP Cores and Drivers User's Guide
DirectCores, SGCores, and Driver firmware cores that must be localized on the personal computer
where Libero SoC is installed when designing with Microsemi devices.
Microsemi has partnered with key industry leaders in the microcontroller space to provide a robust
SmartFusion
Embedded Workbench
information.
The SmartFusion cSoC is also supported by Keil's latest release, MDK-ARM Microcontroller
Development Kit. Refer to
3.2

Jumpers Settings

The recommended default jumpers settings are listed in the following table. Connect the jumpers with the
default settings to enable the pre-programmed demonstration design to function correctly.
Table 3 • SmartFusion Evaluation Kit Jumper Settings
Jumper Function
J6 Jumper to select second 3.3 V (V3P3_F2)
power supply for board
JP6 Jumper to select either 1.5 V external regulator
or SmartFusion 1.5 V internal regulator
Pin 1–2 = 1.5 V internal
Pin 2–3 = 1.5 V external
JP7 Jumper to select between RVI header or LCP
header for application debug
Pin 1–2 = USB programming and SoftConsole Closed
Pin 2–3 = RVI for Keil U-LINK/IAR J-ink
JP10 Jumper to select JTAGSEL
Pin 1–2 = FPGA, allows A2F200 programming Closed
Pin 2–3 = M3, allows Cortex-M3 processor
debug
ecosystem. SmartFusion cSoCs are supported by the latest IAR Systems
®
for ARM. Refer to
SmartFusion Designing with Keil
UG0209 Revision 7.1
®
System-on-Chip (SoC) (v10.0 or later) from
for downloading and installing Microsemi
Designing SmartFusion with IAR Systems
for more information.
Default Settings
Closed
Closed
Open
–
Open
Open
®
release, IAR
for more
Notes
Allows selection of
A2F200 programming or
Cortex-M3 processor
debug with integrated low-
cost programmer
5
